Bosch i:SY E5 ZR F CX Translation Of Original Operating Instructions page 52

Parts of a suspension fork
2
3
4
5
6
Figure 12: Parts of a suspension fork
1 Fork steerer
2 Sag adjuster (without damper) or
Lockout or
Push button
3 Fork crown
4 Deflection (suspension fork)
5 Damper side (optional)
6 Quick release
7 Fitting gap (L.O.R)
8 Fork end (suspension fork)
9 Quick release axle
10 Air suspension-side (optional)
11 Stanchion
12 Fork bridge
13 Stanchion
14 Air valve (for air suspension systems) or
sag adjuster (steel suspension)
MY23I0a - 42_1.0_22.01.2024
1
14
13
12
11
10
9
8
7
15
16
Tyre clearance
15 Tyre height
16 Tyre passage width
Side view
17 Installation height
18 Offset
Description
17
18
52
