Mounting posi-
tions for install-
ing the laser
optics system
(A)
(B)
1 4
Mounting position for laser optics system with camera module
Mounting position for laser optics system without camera module
Undo the two Allen screws (17) and
13
(18)
(3 mm)
Remove the laser optics system by
14
pulling it upwards
(A)
(B)
e.g. laser optics system with camera module (1)
(without camera)
(1)
97
