Fronius LaserHybrid Ultracompact Operating Instructions Manual page 85

(4)
(5)
(6)
(4)
(5)
Connect the hose (5) and adapter (4)
5
from the laser welding head scope of
supply
Connect hose
6
Fit flow rate meter (6) to the hose and
7
adapter
Turn on air supply
8
Set flow rate to 25 l/min using a small
9
slotted screwdriver
Remove flow rate meter (6)
10
Disconnect hose (5) and adapter (4)
11
83
