Summary of Contents for Fronius TS 5kA-3
- Page 1 Quick Start Guide Fronius Smart Meter TS 5kA-3 Fronius Smart Meter TS 5kA-3 manuals.fronius.com/ html/4204260348 FIND MORE INFORMATION 42,0410,2495 007-23032023...
- Page 2 Communication Standard RS485 - 3 conductors Protocol Modbus RTU Min. Softwareversion Datamanager 2.0: 3.16.1 / Fronius Symo Hybrid: 1.16.1 / Fronius GEN24: 1.12.1 Screw terminal Measuring input / neutral line 1 - 4 mm² Output (data communication /Auxiliary power supply) 0,05 - 2,5 mm²...
- Page 3 Mounting Auxiliary Power Supply Power Wiring 1 - 4 mm² 0,6 Nm L/N/+/- 100 - 240 V AC/DC (± 10%) N/L/-/+ 1 Phase, 2 Wires - CT 1 Phase, 2 Wires - CT 1 Phase, 2 Wires - VT/CT 1 Phase, 2 Wires - VT/CT 2 Phases, 3 Wires - CT 2 Phases, 3 Wires - CT 2 Phases, 3 Wires - VT/CT...
- Page 4 Fronius Solar.start 0010 P 14 START INSTALLATION LOGIN Log in with your Fronius credentials (email adress & password) in order to get the most out of the PV System. Installing a new product does not require a Login. Imprint & Contact Data Privacy Terms &...
