Inserting/replacing feed rollers

Preparations

Inserting/replac-
ing drive rollers
(1)
(2)
(1)
(2)
4
(3)
Remove the two Allen screws (2)
1
(3 mm)
Remove the drive rollers cover (1)
2
(2)
Disconnect the external wirefeeding
1
hose
Swing clamping stirrup open (1)
2
Remove threaded shaft (3)
3
Remove drive roller (2)
4
3
77
