Fronius LaserHybrid Ultracompact Operating Instructions Manual page 98

96
1 0
1 0
1 0
(10) (11)
1 1
(14)
(15)
1 1
(16)
Remove the four Allen screws (10) -
10
(13) from the underside of the laser
welding head
(2.5 mm)
1 0
(12) (13)
Disconnect cooling water hoses (14)
11
and (15)
Remove the two Allen screws (16) and
12
(17)
(3 mm)
(17)
