  • Page 1 Instruction for Use 19" Color and Grayscale Monitor Important Please read the Safety Information and the information delivered with the product carefully to familiarize yourself with safe and effective usage.

  • Page 2: Legal Information

    Note the following: WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech‐ nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Connecting the signal cable ................... 20 DIP switches (for SMD 19102 only) ............... 21 Connecting the power cable .................. 21 Installing the base and cable (SCD 19102) ............22 Serial interface ....................... 25 6 Start-up ........................... 27 Switching on the monitor ..................27 Operator controls ....................
  • Page 4 13.2 Warranty ........................ 87 13.3 Repairs ........................87 13.4 Environmental protection ..................87 13.5 Accessory devices ....................87 13.6 Trademarks ......................88 13.7 China RoHS (Restriction of Hazardous Substances) ..........89 SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 5 Table of contents 13.8 Disposal of materials containing mercury .............. 91 Index ..........................93 SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 6: Introduction

    The monitors are available in color and gray scale variants: • Color monitor – SCD 19102 C, version without protective front pane, without multifunctional stand – SCD 19102 CP, version with protective front pane, IPx2 at front – SCD 19102 D, version without protective front pane, with multifunctional stand •...

  • Page 7: Safety Instructions

    Note Image quality To maintain constant image quality, EIZO recommends cleaning the monitor on a regular basis and checking image properties in accordance with all applicable local regulations. User In the following, health personnel such as radiologists or MTAs are referred to as the "user".
  • Page 8 No contact between device and patients The device is not suitable for direct contact with patients. Device and patient must never be touched simultaneously. Otherwise there is a danger to life and limb. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 9 Only use power cables approved for China. These power cables are identified by the labels "CCC" or "CQC". Observe the country-specific regulations Observe all regulations of the country in which the device is used. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 10 If the device is brought into a room with a higher or rising temperature, condensed water will form in and on the device. Do not switch on the device until the condensed water has evaporated. Otherwise the device could be damaged. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 11 Note that monitors can fail as a result of aging, and that image properties such as brightness, con‐ trast, and color value can change. Do not touch the monitor screen Touching the screen can result in brief image distortions due to mechanical pressure or electrostatic discharge. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 12: Product-Specific Safety Instructions

    To ensure that a system comprising a monitor and base meet the requirements of standard EN 60601, select a stand for subsequent installation that meets this standard. See also Installing the monitor Installing the base and cable (SCD 19102) SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 13: Description

    IEC 601. The monitors also comply with safety standards UL 2601 and EN 60601-1. Performance features SCD 19102 19" color monitor and SMD 19102 19" gray scale monitor have the following features, which permit a wide area of applications. Compact design The monitor benefits from low weight and a small foot print, as well as improved perform‐...
  • Page 14 Protective glass The SCD 19102 CP and SMD 19102 CP have anti-glare protective glass fitted over the top of the LCD panel to protect the surface of the panel against bumps and scratches. The front of the monitor is protected against moisture (IPx2 protection). The space between the pro‐...

  • Page 15: Setup And Installation

    4.1 Installation site Setup and installation CAUTION Changes to device Do not make any mechanical or electric changes to the device. EIZO GmbH will not be held liable if changes are made to the device. Installation site Provide adequate ventilation Ventilation slots are located on the rear of the housing.

  • Page 16: Installing The Monitor

    7 mm minimum / 9 mm maximum Torque Max. 3 Nm Fig. 1: Insertion depth of mounting screws See also Product-specific safety instructions Installation site Installing the base and cable (SCD 19102) SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 17: Connecting

    The monitor must not share a power supply with motors or valves (interference peaks!). NOTICE Disconnecting from line power Always set the power switch to "Off" before disconnecting the device from power. Other‐ wise the device could be destroyed. See also Electromagnetic compatibility SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 18: Connector Location

    The power switch is not covered and is freely accessible. Fig. 2: Rear view of SCD / SMD 19102 Overview of signals and connections Fig. 3: Overview of signals and connections SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 19: Connection Panel

    A connection panel for the signals and power supply is located on the back of the monitor SCD 19102 Fig. 4: Connection panel of the SCD 19102 color monitor SMD 19102 Fig. 5: Connection panel of the SMD 19102 gray scale monitor...

  • Page 20: Connecting The Signal Cable

    The DVI cable can be connected in two ways: • With DVI digital signal or • With DVI analog signal (SCD 19102 only) BNC sockets (SoG / H / V) With a wire (R or G or B, with composite synchronization): •...

  • Page 21: Dip Switches (For Smd 19102 Only)

    Open and close the connection panel using an appropriate tool. • Insert the appliance plug of the supplied power cable into the line power socket. • The power cable can be secured using a cable grip. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 22: Installing The Base And Cable (Scd 19102)

    Connecting 5.8 Installing the base and cable (SCD 19102) CAUTION • Only use the power cable in the scope of delivery, or a cable with protective conductor and appliance plug to DIN 49 547, IEC 320 (max. length 3 m). Furthermore, the cable must adhere to all local safety regulations applicable to the specific country in which the monitor is used.
  • Page 23 Connecting 5.8 Installing the base and cable (SCD 19102) 3. First insert two screws into the bottom two drilled holes of the stand. 4. Then insert the remaining screws into the top two drilled holes. 5. Slowly lower the monitor.
  • Page 24 Connecting 5.8 Installing the base and cable (SCD 19102) 8. Route the connecting cable in the cable duct. WARNING: Do not route the connecting table too tightly in the cable duct When the monitor turns on its axis there is a risk of bending or crushing the connecting cable.

  • Page 25: Serial Interface

    Fig. "Possible configuration – serial bus mode" by "1". The socket is located on the left (landscape version) or at the top (portrait version) on the back of the monitor, right next to the VGA plug. • 6-pin mini-DIN socket (downstream): SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 26 Service socket for measuring instruments Fig. 8: Possible configuration – serial bus mode * Photometer is a generic term for the measuring instrument suggested by EIZO GmbH Dis‐ play Technologies: • Advanced Serial Luminance Meter with adapter from 9-pin Sub-D to 6-pin mini-DIN sock‐...

  • Page 27: Start-Up

    The status LED is lit when power is supplied to the device and the power switch is set to On. Key functions In the OSD menu, the keys have the following functions: Situation Action Always Scrolling Submenu is selected Select submenu Function is selected Increase/change value SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 28 Function is selected Decrease/change value All menus except the "Exit OSD" Return to previous menu level (settings are re‐ menu tained) "Exit OSD" menu Return to main menu (settings are retained) SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 29: Description Of Osd Menu

    The OSD menu is used to make settings for operation of the monitor with a source. Parts of the OSD menu can also be used without an input signal. See also Exit OSD Menu functions Service level 2 functions SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 30: Menu Functions

    DVI signals. Manual changes to these val‐ ues are not recom‐ mended, as this can re‐ sult in an impairment of picture quality (loss of gray scales). SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 31 With identical monitor and graphics card set‐ tings, the complete pic‐ ture to be displayed fills the display area of the monitor with the exact number of pixels. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 32 The picture is zoomed to square format. Picture source Select source for main display Selection of picture source for full format image. If you call this OSD menu, the current source is displayed. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 33 "Auto functions" are execut‐ With "Off", the bright‐ ness and contrast are not set when the "Auto functions" are execut‐ Note: This function is not available for "Sync on green signals". SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 34 If the vertical lines are still slightly fuzzy, adjust the "Frequency/Phase" setting. Note: We recommend displaying a vertical line from the "Pixel On/Off" test pattern. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 35 "sharpest" picture, as it does the least fil‐ tering. Filter No. 5 filters the most; the greatest dan‐ ger exists with this filter that details can no lon‐ ger be recognized. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 36 Change the window size under "PIP size" PIP horizontal position Slider control Shift the PIP window in the horizontal direction PIP vertical position Slider control Shift the PIP window in the vertical direction SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 37 See "Sharpness" in the "Others" menu: De‐ scription of details via the filters. PIP image horizontal Slider control Shift the image in the position horizontal direction in (only for analog signal) the PIP window SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 38 Setting of vertical posi‐ tion of OSD menu Default: Down Background Opaque Selection of OSD back‐ ground (Opaque or Transparent Transparent). Default: Opaque Dimmed Adjust the brightness of the status LED. Default: Dimmed SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 39 Only the source can be changed by any user with the OSD keys without the need for a key com‐ bination. Note: See Lock/unlock OSD menu SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 40 Default: On • When "On" is set, the backlight cannot be changed in the "Brightness/ contrast" menu. • When "Off" is set, the backlight can be changed in the "Brightness/ contrast" menu. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 41 Note: The higher the tab setting, the longer it will take for a desired timing change to occur (delayed by a number of milliseconds). SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 42 700 mV if the video level is limited at this value). Note: A specific test pattern and timing are prerequisites. The A/D converters have already been fac‐ tory-set and need not be readjusted. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 43: Exit Osd

    Note: If the OSD menu is exited by changing the timing or switching off the monitor, the changes made are saved. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 44: Service Level 2 Functions

    6.3 Description of OSD menu 6.3.4 Service level 2 functions NOTICE "Servicelevel 2" is restricted to service personnel trained by EIZO GmbH Display Technol‐ ogies. The "Servicelevel 2" menu can be accessed from the OSD main menu. Key combination for opening "Servicelevel 2"...
  • Page 45 Custom settings Custom settings can be 1 ... 5 number saved here A total of 5 custom settings can be generated. The digit is the code number for the memory location. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 46 Example: 10010 ⇒ Ad‐ dresses 1 and 4 have been allocated. Reset custom Execute Clears the content of the settings five memory locations SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 47 • All the pixels on the dis‐ play area are activated (exception: The first col‐ umn on the left of the panel remains black). Test of columns or line driver SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 48 Serial interface The serial interface can be activated or deactivat‐ Default: On If the serial interface is de‐ activated ("Off"), it is possi‐ ble to suppress e.g. the downloading of firmware. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 49 Exact Modes that have al‐ ready been stored. Suitable for direct entry of Force Mode data that have already been determined. Note: See Monitor adjust‐ ment - Force Mode SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 50 160 cd For SMD 19102: Operation time above 400 cd For SCD 19102: Information Operating hours meter Operation time be‐ low 160 cd For SMD 19102: Operation time be‐ low 400 cd SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 51 Setting the best PLL phase gain The best PLL phase gain can be obtained with the "Check-11" pixel on / pixel off image from the Quan‐ tum Data 802R video test generator. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 52 Setting the best PLL fre‐ quency gain The best PLL frequency gain can be obtained with the "Check-11" pixel on / pixel off image from the Quantum Data 802R video test generator. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 53: Lock/Unlock Osd Menu

    Lock You can lock the OSD when it is inactive. To lock, enter the following key combination without interruption: SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 54: System Settings

    The brightness and contrast must be adjusted for the respective graphics card in the system on site due to different output levels. CAUTION The exact brightness and contrast settings are possible only with a photometer. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 55: Monitor Adjustment - Video Source/Graphics Card

    Please note that these settings have no impact on the calibration in the look up table: SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 56: Monitor Adjustment - Lut

    You can select between five different LUT values in this menu. The values saved in the monitor are shown in a table in the OSD window. Note Additional information is available in the QA software instruction manual. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 57: Monitor Adjustment - Force Mode

    Field 1 consists of the lines 1 to 262 1/2, and field 2 of the lines 262 1/2 to 525. Only a few lines are displayed at the top and bottom of each field. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 58 Fig. 12: Interlaced scanning system Fig. 13: Non-interlaced scanning system A non-interlaced image is output on the screen in that all horizontal lines are scanned from top to bottom in one scan. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 59 3. Enter the timing data into the individual input fields using the Menu, Up and Down keys. 4. Select either "For static pictures" or "For motion pictures" in line 6 in the "Blind mode" menu and confirm using key 2. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 60 "For static pictures" or "Reset" can be selected in line 6 in the "Blind mode" menu. Note: If the "Reset" setting is selected, all learned values are deactivated in the current Force Mode window. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 61 Sequence for setting a timing 1. Determine start values using auto function 2. Optimize scanning frequency 3. Optimize geometry and resolution Step-by-step instructions for setting a timing can be found in the next three sections. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 62 Note: For progressive timings with an image refresh rate greater than 60 Hz, only the items "For static pictures" or "Reset" can be selected in the "Live mode" menu. 4. Execute the "Force" command using key 2. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 63 If the interval between the interferences becomes larger, and these therefore also become fewer, you are moving the slider in the correct direction. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 64 Note: For progressive timings with an image refresh rate greater than 60 Hz, only the items "For static pictures" or "Reset" can be selected in line 6 in the "Live mode" menu. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 65 1. Open a test pattern with a clearly defined border (e.g. SMPTE image). 2. Open the "Live mode" menu: Main menu → Servicelevel 2 → Force Mode → Live mode. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 66 The location in the "Save custom settings" number where the 1 is set depends on the selected "Custom settings number". For example, if you have selected "1" as the "Cus‐ tom settings number", the 1st position of "Save custom settings" us set to "1". SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 67 If the motion image improvement is to be activated, the setting for this must be changed from "Inactive" to "Active" either in the "Servicelevel 2" → "Others" menu or in the "Blind mode" or "Live mode" of the Force Mode menu. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 68 "S-Video" and "Composite Video". The staircase signals can occur if a sig‐ nal source with motion image improvement is active in the main picture. See also Service level 2 functions Live mode SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 69: Operation

    Service if settings have to be changed. CAUTION If keys are locked contact service If the keys are locked, contact the service department to unlock them. Unlocking them yourself invalidates the warranty SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 70: Cleaning And Maintenance

    (70%) Aldehyde • Melsitt • Aldasan 2000 • Cidex • Kohsolin • Cidex (2.4% glutaraldehyde • Gigasept FF solution) Chlorine derivatives • Terralin Quartamon Med • Sodium hypochlorite (10%) SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 71 Forbidden cleaning agents and disinfectants Agent class Tested cleaning agents and disinfectants Peroxide compounds Perform Dismozon pur These cleaning agents and disinfectants can bleach the paint after a longer period of appli‐ cation. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 72: Troubleshooting

    "Auto adjust" panel Other information output via two-color LEDs Monitor status LED orange No fault; "Power down" was switched on and acti‐ vated. LED green Video signal recognized, no fault SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 73: Technical Specifications

    Optically non-reflective protective glass on both sides Backlight 6 CCFT (cold cathode fluorescent tubes) Lifetime of backlight Typically 45,000 hours for CCFT (applies to an ambient temperature for the back‐ light of 25 °C) SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 74: Voltage Supply

    Sync level: TTL-compatible SoG signal • Video level: 0.5 ... 1.0 V • Sync level: 0.2 ... 0.3 V Digital signal input DVI input Over DVI-I socket, single link via DVI SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 75: Controls And Connectors

    • 1x RS 232 socket (6-pin mini-DIN socket) 10.6 Mechanical design Housing components For SCD / SMD 19102 CP only: Protective glass Optically non-reflective protective glass on both sides SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 76: Climatic Conditions

    Air pressure 1053 ... 540 hPa 10.8 Mechanical requirements Operation Vibrations According to EN 60068-2-6 10 ... 58 Hz at ± 0.075 mm deflection 58 ... 500 Hz at 10 m/s² SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 77: Safety Specifications

    The SCD / SMD 19102 C and SCD / SMD 19102 CP monitors are delivered without a stand. To ensure that a system comprising a monitor and base meet the requirements of standard EN 60601, select a stand for subsequent installation that meets this standard. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 78: Electromagnetic Compatibility

    Noise immunity EN 61000-4-6 150 kHz ... 80 MHz 3 V/m 80 % AM 1 kHz Magnetic constant fields EN 61000-4-8 Max. 4000 A/m Magnetic alternating fields EN 61000-4-8 Max. 10 A/m SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 79: Dimensioned Drawings

    Dimensioned drawings 11.1 SCD / SMD 19102 C/CP (without stand) Dimensioned drawings All dimensions in mm 11.1 SCD / SMD 19102 C/CP (without stand) 11.1.1 Front view SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 80: View From Left

    Dimensioned drawings 11.1 SCD / SMD 19102 C/CP (without stand) 11.1.2 View from left SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 81: Rear View

    Dimensioned drawings 11.1 SCD / SMD 19102 C/CP (without stand) 11.1.3 Rear view 11.1.4 View from above SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 82: Scd / Smd 19102 D (With Stand)

    Dimensioned drawings 11.2 SCD / SMD 19102 D (with stand) 11.2 SCD / SMD 19102 D (with stand) 11.2.1 Front view SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 83: View From Left

    Dimensioned drawings 11.2 SCD / SMD 19102 D (with stand) 11.2.2 View from left 11.2.3 View from above SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 84: Spare Parts / Accessories

    DVI transmission path. Digital graphics connection supports the transmission of high-quality video data. Using the DVI cable set from EIZO, this data can be transmitted over a distance of up to 36 m without any reduction in quality.
  • Page 85 Different cables and adapters allow problem-free integration of our monitors, even in ex‐ tremely complex systems. Product Order No. DVI cable, single link, 3 m 6GF6980-1TA07 BNC to VGA cable 6GF6980-1TB04 SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 86: Appendix

    WEEE marking: Product must be disposed of separately; materials may be recycled. (name plate). Marking according to ACPEIP (China-RoHS). (name plate) "On" symbol (voltage) (power switch) "Off" symbol (voltage) (power switch) Input for service calls. (PS2 socket) SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 87: Warranty

    Please contact the sales partner from whom you purchased the product. 13.4 Environmental protection Please observe all local requirements and laws pertaining to the disposal of devices. 13.5 Accessory devices Connected devices such as PCs must meet the relevant safety standards. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...

  • Page 88: Trademarks

    13.6 Trademarks EIZO Logo is a registered trademark of EIZO Corporation in Japan and other countries. EIZO is a registered trademark of EIZO in Japan and other countries. RadiForce is a registered trademark of RadiForce in Japan and other countries.

  • Page 89: China Rohs (Restriction Of Hazardous Substances)

    EFUP shall be done in accordance with the Product Maintenance Procedures. This product must not be disposed of as unsorted municipal waste, and must be collect‐ ed separately and handled properly after decommissioning. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 90 There is no risk, because the substance is integrated in the glass of the flat lamp.The flat lamps of the LCD Flat screen for medical backlights contain Mercury. The Mercury is in‐ side the CCFL tubes. SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 91 Este produto incorpora dispositivos que poderão conter mercúrio, devendo ser reciclado ou eliminado de acordo com as leis locais, estatais ou nacionais. (Dentro deste sistema, as lãmpadas de fundo no écran do monitor podem conter mercúrio.) SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 92 Το συγκεκριμένο προϊόν περιλαμβάνει συσκευές που ενδέχεται να περιέχουν υδράργυρο, η ανακύκλωση ή απόρριψη του οποίου πρέπει να πραγματοποιείται σύμφωνα με τον τοπική, πολιτειακή ή εθνική νομοθεσία. (Στο συγκεκριμένο σύστημα, οι λυχνίες οπίσθιου φωτισμού στην οθόνη του μόνιτορ περιέχουν υδράργυρο) SCD 19102 / SMD 19102 Instruction for Use, 05/2013...
  • Page 93 Saving Fine adjustment User General safety instructions Gray scale setting Ventilation Video input 20, 75 Lifetime of backlight Live mode Warranty Mini-DIN socket Motion image improvement 49, 68 Zero error rate SCD 19102 / SMD 19102 Instruction for Use, 04/2013...
  • Page 94 Siemensallee 84 76187 Karlsruhe Germany Instruction for Use, 05/2013 SCD 19102 / SMD 19102 A5E01588521A-005 Copyright © 2013 EIZO GmbH. All rights reserved.
