Important
Please read this User's Manual and Setup
Manual (separate volume) carefully to
familiarize yourself with safe and effective
usage.
PRECAUTIONS
Chapter 1 Features and Overview
1-1 Features
1-2 Switches and Indicators
1-3 Functions and Basic Operation
Chapter 2 Settings and Adjustments
2-1 Utility Disk
2-2 Screen Adjustment
2-3 Color Adjustment
2-4 Off Timer/Power Saving Settings
2-5 Screen Size Selection
2-6 Power Indicator/EIZO Logo Display Setting
2-7 Beeper Settings
2-8 Locking Switches
2-9 Setting Adjustment Menu Display
2-10 Viewing Information/Setting Language
2-11 Resumption of Default Setting
Chapter 3 Connecting Cables
3-1 Connecting Two PCs to the Monitor
3-2 Connecting Peripheral USB Devices
Chapter 4 Troubleshooting
Chapter 5 Reference
5-1 Attaching an Arm (Option)
5-2 Cleaning
5-3 Specifi cations
5-4 Glossary
5-5 Preset Timing
How to Setup
Please read the Setup Manual (separate volume)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexScan S2111W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eizo FlexScan S2111W

Summary of Contents for Eizo FlexScan S2111W

  • Page 1 2-1 Utility Disk 2-2 Screen Adjustment 2-3 Color Adjustment 2-4 Off Timer/Power Saving Settings 2-5 Screen Size Selection 2-6 Power Indicator/EIZO Logo Display Setting 2-7 Beeper Settings 2-8 Locking Switches 2-9 Setting Adjustment Menu Display 2-10 Viewing Information/Setting Language 2-11 Resumption of Default Setting...

  • Page 2: Safety Symbols

    EIZO NANAO CORPORATION’s receipt of said information Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifi cations are subject to change without notice.

  • Page 3: Precautions

    PRECAUTIONS IMPORTANT • This product has been adjusted specifi cally for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specifi ed in the specifi cations. •...
  • Page 4 WARNING Place the unit at the strong and stable place. A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your dealer for advice. Do not continue using a damaged unit.
  • Page 5 WARNING Handle the power cord with care. • Do not place the cord underneath the unit or other heavy objects. • Do not pull on or tie the cord. If the power cord becomes damaged, stop using it. Use of a damaged cord may result in fi re or electric shock.
  • Page 6 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury. When handling the unit, grip the bottom of the unit fi rmly with both hands ensuring the panel faces outward before lifting.

  • Page 7: Lcd Panel

    LCD Panel In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in lower brightness is recommended. The LCD panel is manufactured using high-precision technology. However, note that the appearance of any missing pixels or lit pixels does not indicate damage to the LCD monitor.

  • Page 8: Table Of Contents

    ... 20 ● To turn off the Power indicator while a screen is displayed [Power Indicator Setting] ... 20 ● To display EIZO logo [EIZO Logo Appearing Function] ... 20 CONTENTS Beeper Settings ... 20 ● To set the beeper [Beep] ... 20 Locking Switches ...

  • Page 9: Chapter 1 Features And Overview

    • FineContrast mode to allow the best mode for screen display • The utility software “ScreenManager Pro for LCD” (for Windows) to control the monitor from a PC with mouse/keyboard is included (refer to the EIZO LCD Utility Disk). • The ArcSwing 2 Stand enables to adjust the monitor height and monitor angle freely...

  • Page 10: Functions And Basic Operation

    1-3 Functions and Basic Operation To adjust the screen and color Main menu (Refer to page 9 for operation) • The Adjustment menu and the FineContrast menu cannot be displayed at the same time. FineContrast menu Color adjustment Simple adjustment [FineContrast mode] This function allows easy selection of a desired mode from fi...

  • Page 11: Basic Operation Of Adjustment Menu

    [Information] to check settings, usage time, etc. Language ● [Language] to select ScreenManager’s language. EIZO Logo Display Setting ● [EIZO Logo Appearing Function] to display or not to display the EIZO logo. Locking Adjustment ● [Adjustment Lock] to lock operation of the monitor.

  • Page 12: Chapter 2 Settings And Adjustments

    Chapter 2 Settings and Adjustments 2-1 Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the application software programs. ● Disk Contents • Disk contents and software overview The disk includes a monitor information file, application software programs for adjustment, and User’s Manual.

  • Page 13: Screen Adjustment

    ● Advanced Adjustment Run the Screen Adjustment Program. Load the EIZO LCD Utility Disk on the PC, and start the Screen Adjustment Program compatible with the PC in use. After the program starts up, perform the adjustment in step 4 following the instructions of the program.
  • Page 14 Perform advanced adjustments for the following using the <Screen> menu of the Adjustment menu. ● To eliminate vertical bars [Clock] (1) Choose <Clock> from the <Screen> menu, and touch The <Clock> menu appears. (2) Adjust the clock with The adjustment is completed. ●...
  • Page 15 , and then horizontal , and touch Attention • [Smoothing] is disabled when the screen is displayed in the following resolutions. • 1680 × 1050 (S2111W) • 1920 × 1200 (S2411W) • Select [Normal] during “Enlarged” mode. Chapter 2 Settings and Adjustments...

  • Page 16: To Update Color Setting Of Finecontrast Mode

    2-3 Color Adjustment Simple adjustment [FineContrast mode] This function allows you to select the best display mode for monitor brightness, etc. ● FineContrast Mode An appropriate display mode is selectable out of fi ve modes. Mode Custom Available for making desired setting. Suitable for color matching with sRGB compatible sRGB peripherals.

  • Page 17: Advanced Adjustments [Adjustment Menu]

    Advanced Adjustments [Adjustment menu] Independent setting and saving of color adjustment are available for each FineContrast mode. ● To select an appropriate mode for images ✓ : Adjustment available −: Invalid for adjustment Icon Function Custom ✓ Brightness ✓ Temperature ✓...

  • Page 18: To Set/Adjust Color

    Menu Description Gain To adjust red, green, and blue to a desired color tone respectively NOTE • Values shown in percentage are available only as reference. 6 Colors To adjust <Hue> and <Saturation> in Red, Yellow, Green, Cyan, Blue, and Magenta respectively Enhancer ContrastEnhancer (Refer to page 35)

  • Page 19: Off Timer/Power Saving Settings

    2-4 Off Timer/Power Saving Settings ● To set monitor power-off time [Off Timer] This function allows the monitor to automatically turn off after a specifi ed time has passed. This function serves to reduce afterimages caused when the monitor screen is left on for a long time period without use. Use this function when an image is displayed throughout the day.

  • Page 20: To Set Monitor Power-Saving [Vesa Dpms/Dvi Dmpm]

    ● To set monitor power-saving [VESA DPMS/DVI DMPM] ■ Analog input This monitor complies with the VESA DPMS standard. [Power Saving System] Operating Power STAND-BY saving SUSPENDED OFF [Procedure] (1) Choose <PowerManager> from the Adjustment menu, and touch The <Set> menu appears. (2) Select “VESA DPMS”...

  • Page 21: Screen Size Selection

    2-5 Screen Size Selection ● To change screen size [Screen Size] The image with the resolution other than the recommended resolution is displayed in full screen automatically. You can change the screen size by using <Screen size> from <Others> menu. Menu Displays an image in full screen.

  • Page 22: Power Indicator/Eizo Logo Display Setting

    ● To display EIZO logo [EIZO Logo Appearing Function] When this unit is turned on, the EIZO logo appears at the center of the screen. Selection to display or not to display the logo is available with this function. [Procedure] (1) Touch to power off the unit.

  • Page 23: Locking Switches

    2-8 Locking Switches ● To lock operation [Adjustment Lock] This function locks the switches to retain the status adjusted or set once. Switches that can • (Enter switch) Adjustments/settings using be locked Adjustment menu • (Auto Adjustment switch) Switches that cannot •...

  • Page 24: Viewing Information/Setting Language

    Translucent Set the transparency for menu display using the following procedure. (1) Choose <Others> from the Adjustment menu, and touch (2) Choose <Menu Settings> from the <Others> menu, and touch (3) Choose <Translucent> from the <Menu Settings> menu, and touch The <Translucent>...

  • Page 25: Resumption Of Default Setting

    2-11 Resumption of Default Setting ● To reset color adjustment [Reset] The hue in the color mode currently set will revert to the default settings (factory settings). (1) Choose <Color> from the Adjustment menu, and touch (2) Choose <Reset> from the <Color> menu and touch The <Reset>...

  • Page 26: Chapter 3 Connecting Cables

    Chapter 3 Connecting Cables 3-1 Connecting Two PCs to the Monitor Two PCs can be connected to the monitor through the two DVI-I connectors on the back of the monitor. Connection examples DVI-I connector (SIGNAL1) SIGNAL1 Signal cable (supplied FD-C39) D-sub mini Signal cable 15-pin...

  • Page 27: To Set Priority Of Pc To Be Displayed [Input Priority]

    (1) A PC equipped with a USB port or another USB hub connected to a USB compatible PC (2) Windows 98/Me/2000/XP or Mac OS 8.5.1 or later (3) Supplied EIZO USB cable (MD-C93) ● Connection Procedure (Setup of USB Function) (1) Connect the monitor fi...

  • Page 28: Chapter 4 Troubleshooting

    Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. • No-picture problems → See No.1 - No.2. • Imaging problems → See No.3 - No.14. • Other problems → See No.15 - No.18. •...
  • Page 29 • [Smoothing] is disabled when the screen is displayed in the following resolutions. • 1680 × 1050 (S2111W) • 1920 × 1200 (S2411W) • Select [Normal] during “Enlarged” mode. • Check whether the FineContrast menu is running. (Refer to “Simple adjustment [FineContrast mode]”...

  • Page 30: Chapter 5 Reference

    5-1 Attaching an Arm (Option) The stand can be removed and replaced with an arm (or another stand) to be attached to the monitor. Use an arm or stand of EIZO option. [Attaching] Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down.

  • Page 31: Cleaning

    5-2 Cleaning Clean the monitor periodically to keep the monitor clean and extend its life. Cabinet Clean the cabinet with a soft cloth dampened with little mild detergent. LCD Panel • Clean the LCD panel with a soft cloth such as cotton cloth or lens cleaning paper.

  • Page 32: Specifi Cations

    5-3 Specifi cations S2111W LCD Panel 21.1-inch (539 mm) TFT color LCD with anti-glare hard coating Viewing angle: Vertical 178°, Horizontal 178°(CR:10 or more) Dot Pitch 0.270mm Horizontal Scan Frequency Analog: 24-82kHz (Automatic) Digital: 31-65kHz Verticall Scan Frequency Analog: 49-86Hz (Automatic) (1280 ×...
  • Page 33 S2411W LCD Panel 24.1-inch (610 mm) TFT color LCD with anti-glare hard coating Viewing angle: Vertical 178°, Horizontal 178°(CR:10 or more) Dot Pitch 0.270mm Horizontal Scan Frequency Analog: 24-94kHz (Automatic) Digital: 31-76kHz Verticall Scan Frequency Analog: 49-86Hz (Automatic) (1600 × 1200: 49-76Hz, 1920 × 1200: 49-61Hz) Digital: 59-61Hz (VGA TEXT: 69-71Hz) (1080p@50Hz: 49-51Hz) Resolution 1920 dots ×...
  • Page 34 Brightness Smoothing FineContrast Mode PowerManager Screen Size Input Priority Off Timer Menu Settings Menu Size Menu Off Timer Beep Language Outside Dimensions S2111W 501(19.7) 22.7(0.89) 55.6(17.9) 457.6(18.0) Chapter 5 Reference Analog Input 100% Custom VESA DPMS Full Screen Disable Normal...
  • Page 35 S2411W 566(22.3) 22.8(0.9) 520.4(20.5) 522(20.6) Connector Pin Assignment • DVI-I connector 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 Pin No. Signal TMDS Data 2- TMDS Data 2+ TMDS Data2/4 Shield DDC Clock (SCL)
  • Page 36 • USB port Downstream Upstream Series B connector Series A connector Contact No. Signal – Data + Data Ground Option List Cleaning Kit Signal Cable Chapter 5 Reference Remarks Cable power Serial data Serial data Cable ground EIZO ScreenCleaner FD-C16 FD-C39...

  • Page 37: Glossary

    5-4 Glossary Clock The analog input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog input signal is converted to a digital signal for image display. This is called clock adjustment.
  • Page 38 1680 (S2111W) / 1920 (S2411W) horizontal pixels and 1050 (S2111W) / 1200 (S2411W) vertical pixels. At a resolution of 1680 x 1050 (S2111W) / 1920 x 1200 (S2411W), all pixels are illuminated as a full screen (1:1). sRGB (Standard RGB) International standard for “color reproduction and color space”...

  • Page 39: Preset Timing

    5-5 Preset Timing The following table shows factory preset video timing. Mode Dot clock VGA 640×480@60Hz 25.2 MHz VGA 720×400@70Hz 28.3 MHz Macintosh 640× 30.2 MHz 480@67Hz Macintosh 832× 57.3 MHz 624@75Hz Macintosh 1152× 100.0 MHz 870@75Hz Macintosh 1280× 126.2 MHz 960@75Hz VESA 640×480@72Hz 31.5 MHz...
  • Page 40 VESA CVT RB (S2111W) 119.0 MHz 1680×1050 VESA CVT (S2411W) 193.3 MHz 1920×1200 VESA CVT RB (S2411W) 154.0 MHz 1920×1200 1080p@50Hz (S2411W) 148.5 MHz 1920×1080p 1080p@60Hz (S2411W) 148.5 MHz 1920×1080p Chapter 5 Reference Horizontal 64.67 Positive Vertical 59.88 Negative Horizontal 74.56...
  • Page 41 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment.

  • Page 42: Fcc Declaration Of Conformity

    Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specifi ed cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord - Shielded Signal Cable (DVI - D-sub mini 15-pin, the enclesed signal cable) This Class B digital apparatus complies with Canadian ICES-003.
  • Page 43 Dieser Monitor erfüllt die Anforderungen an die Ergonomie nach ISO13406-2 mit dem Videosignal, 1600 × 1050 (S2111W)/1920 × 1200 (S2411W), RGB analog, 0,7 Vp-p und mindestens 60,0 Hz Bildwiederholfrequenz, non interlaced. Weiterhin wird aus ergonomischen Gründen empfohlen, die Grundfarbe Blau nicht auf dunklem Untergrund zu verwenden (schlechte Erkennbarkeit, Augenbelastung bei zu geringem Zeichenkontrast.)
  • Page 44 Vous trouverez toutes les informations sur le recyclage dans les sites Web suivants: Återvinningsinformation för kunder i EU: All information om återvinning fi nns på följande webbsidor: http://www.swico.ch http://www.eizo.de http://www.eizo.se Recycling Information for customers in USA: All recycling information is placed in the EIZO Nanao Technologies, Inc’s website. http://www.eizo.com...
