Eizo SCD 19102 Instructions For Use Manual

Eizo SCD 19102 Instructions For Use Manual

1.3mp 19" lcd monitor
Hide thumbs Also See for SCD 19102:
Table of Contents

Advertisement

Quick Links

Download this manual
Instructions for Use
1.3MP 19" LCD Monitor
Important
Please read the safety information and all information delivered
with the product carefully to familiarize yourself with safe and
effective usage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCD 19102 and is the answer not in the manual?

Questions and answers

Related Manuals for Eizo SCD 19102

Summary of Contents for Eizo SCD 19102

  • Page 1 Instructions for Use 1.3MP 19" LCD Monitor Important Please read the safety information and all information delivered with the product carefully to familiarize yourself with safe and effective usage.

  • Page 2: Legal Information

    Use of EIZO products WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech- nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Setting the image geometry .............. 49 6.8.3 Setting the brightness and contrast ............ 49 6.8.4 Monitor adjustment – video source/graphics card ........ 50 6.8.5 Monitor adjustment – LUT.................  51 6.8.6 Monitor adjustment - Force Mode .............  51 SCD 19102 Instructions for Use, 06/2022...
  • Page 4 10.7 Climatic conditions.................... 70 10.8 Safety specifications .................... 70 11 Dimensioned drawings .................... 71 11.1 SCD 19102 D (with stand) .................. 71 11.1.1 View from front and side ................ 71 11.2 SCD 19102 C/CP (without stand) ................ 72 11.2.1 View from front and side ................ 72 11.2.2 Rear view ....................

  • Page 5: Introduction

    Note This documentation is available in electronic format only. It can be found on the CD-ROM provided and can be downloaded from www.eizo-or.com. 1.2 Intended use Intended purpose The SCD 19102 is intended for the display of still images and moving images from various commercially available devices commonly used in a medical environment, in particular radi- ology.

  • Page 6: User Groups

    Cleaning staff "Cleaning staff" refers to personnel responsible for cleaning medical devices. SCD 19102 Instructions for Use, 06/2022...

  • Page 7: Safety Information

    2 Safety information 2.1 General safety instructions Correct and safe operation of EIZO devices assume professional transport, storage, installa- tion, and connection, as well as careful operation and service. The devices may only be used for applications for which they are intended.
  • Page 8 Only use power cables approved for China. These power cables are identified by the labels "CCC" or "CQC". Observe the country-specific regulations Observe all regulations of the country in which the device is used. SCD 19102 Instructions for Use, 06/2022...
  • Page 9 If the device is brought into a room with a higher or rising temperature, condensed water will form in and on the device. Do not switch on the device until the condensed water has evaporated. Other- wise, the device could be damaged. SCD 19102 Instructions for Use, 06/2022...
  • Page 10 Note that monitors can fail as a result of aging, and that image properties such as brightness, con- trast,and color value can change. Do not touch the monitor screen Due to mechanical pressure or electrostatic discharges, touching the screen can result in brief distur- bances to the image. SCD 19102 Instructions for Use, 06/2022...

  • Page 11: Product-Specific Safety Instructions

    CAUTION Subsequent installation of a stand The SCD 19102 C and SCD 19102 CP monitors are delivered without a stand. To ensure that a system comprising a monitor and base meet the requirements of standard EN 60601, select a stand for subsequent installation that meets this standard.

  • Page 12: Description

    Keep the packaging material for subsequent transport of the device. Device The 1MP 19" LCD Monitor is a SCD 19102. The monitor is offered in the following versions. Product Order number Description SCD 19102 C 6GF62102EE10 Version without protective front pane, without multifunctional stand SCD 19102 CP 6GF62102EE20...
  • Page 13 Using the Force Mode function, the SCD 19102 can be adapted to special timing settings. Protective screen The SCD 19102 CP has anti-glare protective screen fitted over the top of the LCD panel to protect the surface of the panel against bumps and scratches. The front of the monitor is protected against moisture (IPx2 protection).

  • Page 14: Setup And Installation

    Protect the monitor from dust, for example through appropriate construction measures at the installation site. • During transport, use the original packaging or service packaging. Maintain the permissible ambient temperature The permissible ambient temperature range must not be violated. SCD 19102 Instructions for Use, 06/2022...

  • Page 15: Installing The Monitor

    The SCD 19102 has an anti-glare surface that is only effective if the screen is clean and grease-free. The SCD 19102 CP display includes an optically coated protective glass pane, which is well suited for use in a germ-free environment when cleaning agents are used.

  • Page 16: Connecting

    Device settings may only be adjusted by service personnel. NOTICE Disconnecting from line power Always set the power switch to "Off" before disconnecting the device from power. Other- wise the device could be destroyed. SCD 19102 Instructions for Use, 06/2022...

  • Page 17: Connector Location

    The connectors are located in the connection panel behind a cover on the back of the moni- tor. The power switch is not covered and is freely accessible. Fig.: Rear view of the SCD 19102 SCD 19102 Instructions for Use, 06/2022...

  • Page 18: Connection Panel

    Only service may open the connector panel cover. Patients must not be present when the cover is open. CAUTION Connector Connectors may only be plugged in or removed by Service when the device is switched off. SCD 19102 Instructions for Use, 06/2022...
  • Page 19 • When using a BNC to VGA adapter cable, the signal cables, for example, red, green, and blue, must be of the same length to prevent a loss in image quality. • Use only the cables specified by EIZO or the transmission links available from EIZO. Note •...

  • Page 20: Connecting The Power Cable

    Open and close the connection panel using an appropriate tool. • Insert the appliance plug of the power cable into the line power socket. • The power cable can be secured using a cable grip. SCD 19102 Instructions for Use, 06/2022...

  • Page 21: Installing The Base And Cable

    2. Slightly tighten the screws on the mounting plate. 3. First insert two screws into the bottom two drilled holes of the stand. 4. Then insert the remaining screws into the top two drilled holes. 5. Slowly lower the monitor. SCD 19102 Instructions for Use, 06/2022...
  • Page 22 When the monitor turns on its axis there is a risk of bending or crushing the connecting cable. For this reason, the connecting cable must not be routed too tightly in the cable duct. SCD 19102 Instructions for Use, 06/2022...

  • Page 23: Serial Interface

    (landscape version) or at the top (portrait version) on the back of the monitor, right next to the VGA plug. • 6-pin mini-DIN socket (downstream): identified in the Fig. "Possible configuration – serial bus mode" by "3". SCD 19102 Instructions for Use, 06/2022...
  • Page 24 (1, 2, 3, etc. - assign different numbers for the monitors connected via the same bus connection). Settings, measurements, calibration, and automated quality tests can be performed using QA software. SCD 19102 Instructions for Use, 06/2022...

  • Page 25: Start-Up

    Function is selected Increase/change value Function is selected Decrease/change value All menus except the "Exit Return to previous menu level (settings are retained) OSD" menu "Exit OSD" menu Return to main menu (settings are retained) SCD 19102 Instructions for Use, 06/2022...

  • Page 26: Overview Of The Osd Menu

    Start-up 6.3 Overview of the OSD menu 6.3 Overview of the OSD menu The OSD menu is used to make settings for operation of the monitor with a source. Fig.: Overview of OSD menu SCD 19102 Instructions for Use, 06/2022...

  • Page 27: Menu Functions

    Note: The contrast settings are al- ready optimized for digital DVI sig- nals. Manual changes to these val- ues are not recommended, as this can result in an impairment of pic- ture quality (loss of gray scales). SCD 19102 Instructions for Use, 06/2022...
  • Page 28 "User Color", some color levels may be lost.  Red color temp. -32 ... +32 Select red component of display.  Green color -32 ... +32 Select green component of display. temp.  Blue color temp. -32 ... +32 Select blue component of display. SCD 19102 Instructions for Use, 06/2022...
  • Page 29 After switching the monitor off and tal / Composite / on again, the image sources are S-Video /DVI queried in sequence. Analog Note: Alternatively, the source can be selected through a hot key (see the OSD menu → Others → OSD setting). SCD 19102 Instructions for Use, 06/2022...
  • Page 30 Language German, English Use the "Language" menu to se- lect the language of the OSD Default: English menu German or English can be se- lected. English is the delivery de- fault setting. Others SCD 19102 Instructions for Use, 06/2022...
  • Page 31 Filter No. 1 produces the "sharpest" picture, as it does the least filtering. Filter No. 5 filters the most; the greatest danger exists with this fil- ter that details can no longer be recognized. SCD 19102 Instructions for Use, 06/2022...
  • Page 32 Note: The contrast settings are al- ready optimized for digital DVI sig- nals. Manual changes to these val- ues are not recommended, as this can result in an impairment of pic- ture quality (loss of gray scales). SCD 19102 Instructions for Use, 06/2022...
  • Page 33 Shift the image in the horizontal di- zontal position rection in the PIP window (only for analog signal) PIP image vertical Slider control Shift the image in the vertical direc- position tion in the PIP window (only for analog signal) SCD 19102 Instructions for Use, 06/2022...
  • Page 34 PIP window with key 4 on the Inactive front Default: Inactive If "Active" is selected, the PIP win- dow can be opened or closed with the saved settings using key 4 on the front without opening the OSD menu. SCD 19102 Instructions for Use, 06/2022...
  • Page 35 1 ... 5 Gamma curve selection: curve information on the selected Default: LUT 1 curve The LUTs that can be selected are displayed in the table in the OSD menu. Monitor adjustment – LUT [} 51] SCD 19102 Instructions for Use, 06/2022...
  • Page 36 Switch over signal between b/w analog signal) and color operation Monochrome • If a monochrome signal arrives, Default: RGB it is green on the color monitor. • To obtain correct b/w images, set the "Signal" parameter to "Monochrome". SCD 19102 Instructions for Use, 06/2022...
  • Page 37 • Screen resolution • Frequency of the input signal (line frequency and refresh rate) Service level 2 Settings in this menu must only be carried out by service personnel. Service level 2 functions [} 38] SCD 19102 Instructions for Use, 06/2022...

  • Page 38: Exit Osd

    6.6 Service level 2 functions NOTICE "Service level 2" is restricted to service personnel trained by EIZO GmbH Display Tech- nologies. The "Service level 2" menu can be accessed from the OSD main menu. Key combination for opening "Service level 2"...
  • Page 39 Information Remaining margin of backlight that can be used for regulation Note: The data is only displayed when the panel has warmed up (after approx. 20 min). The dis- played value is for information only. SCD 19102 Instructions for Use, 06/2022...
  • Page 40 The 5-digit combination indicates which individual memory ad- dresses have been allocated. Example: 10010 ⇒ Addresses 1 and 4 have been allocated. Reset custom Execute Clears the content of the five memory locations settings SCD 19102 Instructions for Use, 06/2022...
  • Page 41 • All the pixels on the display area are activated (exception: The first column on the left of the panel remains black). Test of columns or line driver SCD 19102 Instructions for Use, 06/2022...
  • Page 42 • Gamma curve • Standard group • Info window settings • Serial interface settings • H-Scaler clip Reboot Execute The processor is reset The power supply unit is not switched off. The monitor restarts. SCD 19102 Instructions for Use, 06/2022...
  • Page 43 Undesirable staircase signals can be reduced in the case of non-interlaced signals (pro- gressive) of up to 60 Hz con- nected to the "VGA" and "DVI Analog" signal inputs. Note: See Motion image improve- ment [} 61] SCD 19102 Instructions for Use, 06/2022...
  • Page 44 Temperature beginning at which the monitor is dimmed limit Default: 60 °C 25 °C - 90 °C Temperature beginning at which Shutdown tem- perature the monitor is switched off Default: 70 °C Information Operating hours meter Operation time above 160 cd SCD 19102 Instructions for Use, 06/2022...
  • Page 45 Setting the best PLL phase gain The best PLL phase gain can be obtained with the "Check-11" pixel on / pixel off image from the Quantum Data 802R video test generator. SCD 19102 Instructions for Use, 06/2022...
  • Page 46 Setting the best PLL frequency gain The best PLL frequency gain can be obtained with the "Check-11" pixel on / pixel off image from the Quantum Data 802R video test generator. SCD 19102 Instructions for Use, 06/2022...
  • Page 47 If the clamp width is set too high a black border appears because the back porch was left and the clamping is reaching the active video signal. SCD 19102 Instructions for Use, 06/2022...

  • Page 48: Lock/Unlock Osd Menu

    Use a screen saver with regularly changing images • Switch off the monitor when it is no longer needed. • The monitor has an energy saving mode: If the application in use supports the energy saving mode, activate it. SCD 19102 Instructions for Use, 06/2022...

  • Page 49: Setting The Image Geometry

    Adjust the contrast so that image sections with 95 % and 100 % gray value still visibly contrast. To adapt the luminosity to the ambient lighting, adjust the backlight brightness. Please note that the factory-set brightness is then no longer maintained. SCD 19102 Instructions for Use, 06/2022...

  • Page 50: Monitor Adjustment - Video Source/Graphics Card

    The monitor is now configured for optimum performance with the installed graphics card. If you are still not satisfied with the luminance, you can increase the black and white values further by adjusting the backlight in the OSD menu. SCD 19102 Instructions for Use, 06/2022...

  • Page 51: Monitor Adjustment - Lut

    Force Mode. This is possible because a large number of known timings are saved in the monitor. Force Mode timings can be saved in the custom settings. Thus, up to five additional Force Mode timings are available. SCD 19102 Instructions for Use, 06/2022...
  • Page 52 Field 1 consists of the lines 1 to 262 1/2, and field 2 of the lines 262 1/2 to 525. Only a few lines are displayed at the top and bottom of each field. Fig.: Interlaced scanning system SCD 19102 Instructions for Use, 06/2022...
  • Page 53 Vertical resolution 3 - Active video (vertical resolution) Total horizontal lines 5 – Total number of lines (horizontal) Horizontal blank pixels 4 – Front Porch (horizontal) Vertical blank pixels 4 – Front Porch (vertical) SCD 19102 Instructions for Use, 06/2022...
  • Page 54 4. Select either "For static pictures" or "For motion pictures" in line 6 in the "Blind mode" menu and confirm using key 2. 5. Execute the "Force" command using key 2. Note: For progressive timings with an image refresh rate greater than 60 Hz, only the SCD 19102 Instructions for Use, 06/2022...
  • Page 55 All settings in "Live mode" must be carried out with the zoom factor "1 to 1" ("Position/ Zoom" menu). Note Always save data with "Force" The timing data are only entered into memory by the "Force" command, and the image is then displayed with the new parameters. SCD 19102 Instructions for Use, 06/2022...
  • Page 56 2. Open the "Live mode" menu: Main menu → Servicelevel 2 → Force Mode → Live mode. 3. Select either "For static pictures" or "For motion pictures" in the "Live mode" menu and confirm using key 2. SCD 19102 Instructions for Use, 06/2022...
  • Page 57 "For static pictures" or "Reset" can be selected in the "Live mode" menu. 4. Execute the "Force" command using key 2. Note: If the "Reset" setting is selected, all learned values are deactivated in the current Force Mode window. SCD 19102 Instructions for Use, 06/2022...
  • Page 58 "For static pictures" or "For motion pictures". The current setting is then saved, and the slider set to the center of the control range. Once you have set the signal frequency optimally, you can continue with the adjustment. SCD 19102 Instructions for Use, 06/2022...
  • Page 59 The inactive resolution range is the unused range between the active resolution and the maximum resolution of the monitor, namely, 1280 x 1024. In Force Mode, this range is dis- played gray (gray scale monitors) or blue (color monitors). SCD 19102 Instructions for Use, 06/2022...
  • Page 60 Timing successfully set The unknown timing has been successfully set, you can now exit the OSD menu. The moni- tor will recognize the newly set timing and set it as saved whenever connected. SCD 19102 Instructions for Use, 06/2022...
  • Page 61 If the motion image improvement is to be activated, the setting for this must be changed from "Inactive" to "Active" either in the "Servicelevel 2" → "Others" menu or in the "Blind mode" or "Live mode" of the Force Mode menu. SCD 19102 Instructions for Use, 06/2022...
  • Page 62 Despite motion image improvement, staircase signals can occur with PIP images of the signal sources "S-Video" and "Composite Video". The staircase signals can occur if a sig- nal source with motion image improvement is active in the main picture. SCD 19102 Instructions for Use, 06/2022...

  • Page 63: Operation

    These are therefore locked for certain applications. Contact Service if settings have to be changed. CAUTION If keys are locked contact service If the keys are locked, contact the service department to unlock them. Unlocking them yourself invalidates the warranty SCD 19102 Instructions for Use, 06/2022...

  • Page 64: Cleaning

    • The front panel is extremely sensitive to mechanical damage. Avoid all scratches, knocks etc. The SCD 19102 CP version with protective glass are much less sensitive in this regard. • SCD 19102 version, without protective glass: Remove water drops immediately; ex- tended contact with water discolors the surface.
  • Page 65 1.6 % water-based ammonia solution Prohibited cleaning agents and disinfectants Agent class Tested cleaning agents and disinfectants Peroxide compounds Perform Dismozon pur These cleaning agents and disinfectants can bleach the paint after a longer period of appli- cation. SCD 19102 Instructions for Use, 06/2022...

  • Page 66: Troubleshooting

    "Auto adjust" reference to the panel Other information output via two-color LEDs Monitor status LED orange No fault; "Power down" was switched on and activated. LED green Video signal recognized, no fault SCD 19102 Instructions for Use, 06/2022...

  • Page 67: Technical Specifications

    Min. 260 cd/m² Horizontal viewing angle At least ± 85° Vertical viewing angle At least ± 85° Protective screen SCD 19102 CP only: Optically non-reflective protective glass on both sides Backlight White LEDs Lifetime of backlight Typically 45,000 hours (applies to an ambient temperature for the backlight of 25 °C) 10.2 Voltage supply...

  • Page 68: Electronics

    Over 1x BNC socket Composite & S-Video • Video level: 0.5 ... 1.4 V • Sync level: 0.2 ... 0.3 V Standards PAL (625 Z / 50 Hz) NTSC (525 Z / 60 Hz) SCD 19102 Instructions for Use, 06/2022...

  • Page 69: Controls And Connectors

    On rear panel, under cover Weight in kg • SCD 19102 C (without base) 6.4 kg (± 0.5 kg) • SCD 19102 CP (without base, with front pane) 7.0 kg (± 0.5 kg) • SCD 19102 D (with base) 9.9 kg (± 0.5 kg) SCD 19102 Instructions for Use, 06/2022...

  • Page 70: Climatic Conditions

    Dimensions (W x H x D) in mm • SCD 19102 C (without base) 423 x 349 x 95 • SCD 19102 CP (without base, with front pane) 423 x 349 x 95 • SCD 19102 D (with base) 423 x 449 ... 547 x 279 10.7 Climatic conditions...

  • Page 71: Dimensioned Drawings

    Dimensioned drawings 11.1 SCD 19102 D (with stand) 11 Dimensioned drawings All dimensions in mm 11.1 SCD 19102 D (with stand) 11.1.1 View from front and side SCD 19102 Instructions for Use, 06/2022...

  • Page 72: Scd 19102 C/Cp (Without Stand)

    Dimensioned drawings 11.2 SCD 19102 C/CP (without stand) 11.2 SCD 19102 C/CP (without stand) 11.2.1 View from front and side 11.2.2 Rear view SCD 19102 Instructions for Use, 06/2022...

  • Page 73: Spare Parts / Accessories

    DVI transmission path. Digital graphics connection supports the transmission of high-quality video data. Using the DVI cable set from EIZO, this data can be transmitted over a distance of up to 36 m without any reduction in quality. The transmission set comprises a receiver and a transmitter that are connected over the CAT cable.

  • Page 74: Appendix

    "On" symbol (voltage). "Off" symbol (voltage). Input for service calls. Symbol for "Comply with the instructions for use". Symbol for "Authorized service personnel only". Symbol for "Dangerous voltage". UK Responsible Person Swiss authorised representative (CH-REP) SCD 19102 Instructions for Use, 06/2022...

  • Page 75: Information On Electromagnetic Compatibility (Emc)

    Appendix 13.2 Information on electromagnetic compatibility (EMC) 13.2 Information on electromagnetic compatibility (EMC) EIZO monitors were designed for the display of images and normal monitor operation. WARNING Special EMC provisions are required for use of the SCD 19102. Installation, assembly, and use must take place in compliance with the following instructions.
  • Page 76 IEC/EN The product should be kept at least 61000-4-8 15 cm away from the source of power frequency magnetic fields during use. Note: V is the alternating current voltage before application of the measurement level. SCD 19102 Instructions for Use, 06/2022...
  • Page 77 RF compliance level, observe the monitor to ensure its proper operation. If improper operation is observed, in some circumstances additional measures may be necessary, such as reorienting or repositioning the device. SCD 19102 Instructions for Use, 06/2022...
  • Page 78 Note: For 80 MHz and 800 MHz, the recommended minimum distance for the higher frequency range applies. Note: This information may not be applicable in all situations. Absorption and reflection by struc- tures, objects, and people impact the propagation of electromagnetic waves. SCD 19102 Instructions for Use, 06/2022...
  • Page 79 For some radio services, only the frequencies for the radio contact from the mobile communica- tions device to the base station (uplink) is included in the table. The carrier is modulated by a square wave with 50 % duty cycle. SCD 19102 Instructions for Use, 06/2022...

  • Page 80: Fcc Declaration Of Conformity

    Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. •...

  • Page 81: China Rohs (Restriction Of Hazardous Substances)

    EFUP shall be done in accordance with the Product Maintenance Procedures. This product must not be disposed of as unsorted municipal waste, and must be col- lected separately and handled properly after decommissioning. SCD 19102 Instructions for Use, 06/2022...
  • Page 82 Applications of hazardous substances in this medical device are required to achieve its intended clinical uses, and/or to provide better protection to human beings and/or to environment, due to lack of reasonably (economically or technically) available substitutes. 产品中有害物质的名称及含量 Table of hazardous substances’ name and concentration. SCD 19102 Instructions for Use, 06/2022...

  • Page 83: Declaration Of Compliance With India Rohs

    13.5 Declaration of compliance with India RoHS 13.5 Declaration of compliance with India RoHS We, EIZO Corporation, hereby declare and guarantee that this product has been designed and manufactured in compliance with the E-Waste management rule 2016 which prohibit the inclusion of the following substances except for the exemptions listed in schedule II.

  • Page 84: Trademarks

    ENERGY STAR is a registered trademark of the United States Environmental Protection Agency in the United States and other countries. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, Radi- Force, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corpora- tion in Japan and other countries.

  • Page 85: Index

    Energy saving  48, 49 Environment  14 User  6 Features  12 Fine adjustment  49, 50 Ventilation  14 Video input  18, 68 General safety instructions  7 Grounding  16 Warranty conditions  83 Image Sticking  48 Live mode  56 SCD 19102 Instructions for Use, 06/2022...
  • Page 86 Carl-Benz-Straße 3, 76761 Rülzheim, Germany Moosacherstrasse 6, Au, CH-8820 Wädenswil, Switzerland 1 Queens Square, Ascot Business Park, Lyndhurst Road, Ascot, Berkshire, SL5 9FE, UK Instructions for Use, 06/2022 SCD 19102 A5E01588521A-009 Copyright © 2022 EIZO GmbH. All rights reserved.
