TransAct Ithaca 90PLUS Series Programmer's Manual page 79

Programmer's Guide
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
11/07/05
PcOS Series 90PLUS
Set clamp open time out
[ESC] [EM] U <n>
1BH 19H 55H <n>
<27> <25> <85> <n>
&%ZU <m > <m >
1 2
[ESC] f
The [ESC] [EM] U <n> command sets the minimum time the clamp will remain
open after an eject form command. This time out must expire before the clamp
will automatically close and return to receipt mode. It will only be used if print
data is received before another station select command.
Where <n> is the delay in two second increments, the minimum time out is 0
seconds, and the maximum is 30 seconds. If <n> = 0, the delay is set to no time
out. The default is configurable.
Set eject wait time
[ESC] [EM] W <n>
1BH 19H 57H <n>
<27> <25> <87> <n>
&%ZW <m > <m >
1 2
none
When a station select command is issued to the printer, the printer checks the
paper path. If there is a form in the paper path, an error is issued, and the printer
enters dejam mode. To allow the printer to receive back to back transactions, the
printer waits before issuing an error for the form to be removed. This time is
known as the eject wait time. The time starts after an eject command and is only
used if a station select command is issued before the time out and there is a form
in the path. Where <n> is the delay in two-second increments, the minimum eject
wait time is zero seconds, and the maximum is 30 seconds. If <n> = 0, the delay
is set to no time out. The default is configurable.
Set eject pause time
[ESC] [EM] D <n>
1BH 19H 44H <n>
<27> <25> <68> <n>
&%ZD <m > <m >
1 2
none
The command sets the delay between when the eject wait process detects that the
form has been removed and the next station select command has started. The
eject pause gives the operator time to completely remove the form. (Only the
smallest 4 bits are used). The default is configurable.
Where <n>: 0
1
2
15
Rev Q
Printer Control Codes
0 ms
5 ms
150 ms, and so on until
750 ms
Station Control
Page 67
