5.9 Graphic Mode
The Series 90PLUS Printer conforms to the full definition of IBM all-points-addressable (APA) graphic
commands. The printer will only print graphics that are 2.8 inches wide (2.4 inches with the narrow print zone)
which can make it difficult to use off-the-shelf graphic generation programs.
If the Series 90PLUS Printer is used with programs that convert text to graphics, the printer will be slower than
if the printer is sent ASCII text. The Series 90PLUS Printer is supported by a Windows' print driver that will
allow applications to select fonts that are supported by the printer.
The Series 90PLUS Printer is not designed to print large quantities of graphical data. If the printer is asked to
print an excessive amount of black, it will break down the job into multiple steps. This protects the printer but
slows the performance. The printer should not be requested to print a white on black image.
5.9.1

Standard APA Graphics

Function
ASCII
Hexadecimal
Decimal
IPCL
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
Description
Page 48
PcOS Series 90PLUS
Print single-density graphics (60 h x 72 v dpi)
1 2
[ESC] K <n> <n>
1 2
1BH 4BH <n> <n>
1 2
<27> <75> <n> <n>
none
1 2
The [ESC] K <n> <n> command prints n1 + 256 * n2 bytes of single-density
graphics (60 dpi).
Print half-speed, double-density graphics (120 h x 72 v dpi)
1 2
[ESC] L <n> <n>
2
1
1BH 4CH <n> <n>
2
1
<27> <76> <n> <n>
none
1 2
The [ESC] L <n> <n> command prints n1 + 256 * n2 bytes of double-density
graphics (120 dpi) at half speed, allowing full and half dots to be printed.
Print full-speed, double-density graphics (120 h x 72 v dpi)
1 2
[ESC] Y <n> <n>
1 2
1BH 59H <n> <n>
1 2
<27> <89> <n> <n>
none
1 2
The [ESC] Y <n> <n> command prints n1 + 256 * n2 bytes of double-density
graphics (120 dpi) at full speed with no consecutive dots. (Full-speed, double-
density graphic mode is generally used to print 120 h x 144 v dpi resolutions in
two passes).
