Printer Control Codes
MICR Reader
Function
ASCII
Hexadecimal
Decimal
IPCL
Return
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
Return
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
Return
Description
Page 72
PcOS Series 90PLUS
Failure Status Bytes
0CFH, 00H
0CEH, 00H
0CDH, 00H
0CCH, 00H
Read Status Bits
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Table 17 MICR status fields
MICR data request
[ESC] mD
1BH 6DH 44H
<27> <109> <68>
&%MD
[ETB] <length> read status, data or [CAN] <length> fault status
The [ESC] mD command asks the MICR reader to return previously read data.
The response is the same as the read command.
MICR load request
[ESC] mL
1BH 6DH 4CH
<27> <109> <76>
&%ML
none
The [ESC] mL command asks the printer to load a previously read document
into print position. No status is returned. If the load fails, the printer enters a load
error mode. In this case, the document will be released and must be reloaded into
the printer using the normal slip path.
MICR eject request
[ESC] mE
1BH 6DH 45H
<27> <109> <69>
&%MP
none
The [ESC] mE command asks the printer to reject the document. The document
is fed through the printer and ejected out of the top. The document is then
released.
Rev Q
Programmer's Guide
Description
Document speed is too slow.
Sensor error has occurred.
Paper jam has occurred.
No read has occurred.
Description
Data is present.
Amount field is present.
Amount field is present with errors.
Transit field check-sum has failed.
Auxiliary On-Us field is present.
Unreadable data is present (not including amount
field).
Always 1
Always 0
11/07/05
