Printer Control Codes
EPOS Codes
Function
ASCII
Description
Note
Function
ASCII
Description
Note
Function
ASCII
Description
Page 98
PcOS Series 90PLUS
Set bar code height
[GS] h <n>
Set the bar code height in dot lines. The Series 90PLUS Printer prints bar
codes as graphics in 8-dot passes. The height used in EPOS is intended for
thermal printers. To allow some compatibility between EPOS and the Series
90PLUS Printer, the value of n is divided by 28. This allows a similar size
bar code to be printed.
Values less than 28 return the printer to the default values defined by the
[ESC] [EM] B command in normal mode.
Set bar code
[GS] k <m> {information} [NUL]
The Series 90PLUS Printer uses the same print functions to print EPOS bar
codes as the normal mode bar codes.
EPOS has two formats for bar codes. One is [NUL] terminated; the other
has a length field. If <m> is greater than 64, the next byte sets the length in
bytes. Only the [NUL] terminated command is supported by the Series
90PLUS Printer.
Where m:
0
UPC A
1
UPC E
2
EAN-13
3
EAN-8
4
Code 39
5
Interleaved 2 of 5 Numeric (0 - 9) only, must be even
If Code 128 is to be printed, it must be printed with the [ESC] b <n>
command as described on page 55.
Real-time command
[DLE] [ENQ] <n>
The Series 90PLUS Printer only supports Commands 2 and 3. Both have the
same effect and reset the printer.
Unlike Epson, this command is filtered out of all other commands. If the
[DEL] [ENQ] <n> is part of some other command (like graphic data), it will
have no effect.
Rev Q
Programmer's Guide
Numeric (0 - 9) only; 11 digits
Numeric (0 - 9) only; 11 digits
Numeric (0 - 9) only; 12 digits
Numeric (0 - 9) only; 6 digits
26 uppercase letters (A - Z); 10 digits
(0 - 9)
number of digits
11/07/05
