General Specifications
3.6.1.2
2.80" (71.1 mm)
3.25" (82.6 mm)

Figure 8 Receipt autocutter position

The autocutter has a cut point and a tear-off point. The tear-off is used to separate the partial cut
cleanly from the next receipt.
The autocutter is positioned 0.9 inch (22.9 mm) from the top of the last line of print to the cut point.
The paper should be fed 1.0 inch (25.4 mm) after the last line is printed and before the cutter is
activated. After the cut, the paper automatically feeds 0.6 inch (15.2 mm) to allow the receipt cut point
to be at the tear-off point.
The first line of print is 1.5 inches (38.1 mm) from the cut. If the first line of the next receipt is to be
closer to the top of the receipt, the receipt can be reversed up to 0.4 inch (10.2 mm). The previous
receipt must, however, be removed before the reverse feed. If the receipt is not to be removed but is to
remain attached to the next receipt, the paper should not be reversed.
The paper should not be fed back into the printer more than 0.4 inch (10.2 mm). If a double-high line
of print is the first line of a receipt, it will be reverse fed 0.1 inch (2.54 mm). If any more paper is
reverse fed, the paper will become unloaded from the knife.
Page 12
PcOS Series 90PLUS

Receipt Printing with the Autocutter

Tear-off
Cut-off
0.60" (15.2 mm)
0.90" (22.9 mm)
0.225" (5.7 mm)
Rev Q
Programmer's Guide
11/07/05
