Character Attribute Commands; Figure 16 Data Sent To Printer For One-Line Double-Wide Print; Figure 17 Example Of One-Line Double-Wide Print - TransAct Ithaca 90PLUS Series Programmer's Manual

Programmer's Guide

5.7 Character Attribute Commands

Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
Example of one line double wide[CR][LF]
This is normal 12 CPI Print[CR][LF]
[SO]
Double Wide[CR][LF]
This is back to normal[CR][LF]
Figure 16 Data sent to printer for one-line
double-wide print
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
11/07/05
PcOS Series 90PLUS
Begin one-line double-wide print
[SO]
0EH
<14>
&%MW
none
The [SO] command causes subsequent characters to be printed at twice the currently
selected character width. For example, 10 cpi becomes 5 cpi, 17 cpi becomes 8.5 cpi,
and so forth. The command will remain in effect until:
1. A valid line terminator is received (CR, LF, or fine line feed);
2. The command is canceled; or
3. The maximum number of characters per line is reached, and the printer performs
an automatic print.
Cancel one-line double-wide print
[DC4]
14H
<20>
&%MN
none
The [DC4] command cancels one-line double-wide mode set by the [SO] command
and allows single- and double-wide characters to be printed on the same line.
Rev Q
Printer Control Codes
Character Attribute Commands

Figure 17 Example of one-line double-wide print

Page 37
