About The Software; Guided Setup - Micromeritics ACCUPYC III Operator's Manual

2 A
BOUT THE
Analysis provides the measurement of sample volume, from which density can be derived
automatically once the sample mass is entered. The unit comes preprogrammed with default
conditions and ready to perform analyses. It can be reprogrammed to meet specific needs.
Analyses can be modified (refer to
control of the primary portions of the analysis: purge and run.
G S
UIDED ETUP
Use the information below to set up the AccuPyc III at first usage or after a factory reset has been
completed.
C R
ONNECT THE
1. Place gas cylinder within 6 feet (2 meters) of the instrument.
2. Connect the proper regulator for the selected gas cylinder:
CGA 580: Nitrogen, helium, argon
n
CGA 320: Carbon dioxide
n
CGA 590: Air, SF6
n
3. Connect the provided 1/8 in. copper tubing from the regulator into the analysis gas inlet
located on the rear of the instrument.
4. Open and close the valve on the gas cylinder.
5. Increase the pressure on the regulator to 22 psig (152 kPag), unless another operating
pressure will be used.
6. Use a soapy solution to verify that the connections from the gas cylinder to the instrument
are leak free.
O : C
PTIONAL ONNECT
A vacuum pump can optionally be connected to the AccuPyc III. An accessory kit is available to
make the proper connections.
O : C
PTIONAL ONNECT
Dry air can be connected to the AccuPyc III and is recommended for analyses at lower
n
temperatures where condensation might happen.
If the analysis temperature is below room temperature and the laboratory is humid, it's a good
n
idea to connect dry air.
Dry compressed air or nitrogen is connected using a 1/8 inch nut.
n
Flow should be set to approximately 2 psig (14 kPag).
n
AccuPyc III Operator Manual
135-42800-01 (Rev -) — Nov 2023
S
OFTWARE
Method on page 2 -
EGULATOR AND
V P
ACUUM
D A
RY IR
21). Modifying these parameters allows
G L
AS INE
UMP

2 About the Software

2 - 1
