R
P
EGULATOR
RESSURE
Tank pressure should be at least 200 psi above regulator pressure. Pressures less
than 200 psi indicates the tank is low on gas.
S
R
ET
EGULATOR
The Purge fill and Cycle fill pressures are specified in the Method. Set the regulator pressure at
the higher of the two, plus 2.0 psig (14 kPag).
For example: If the Purge fill pressure is set to 19.500 psig (134.45 kPag) and the Cycle fill
pressure as 19.000 psig (131.00 kPag), set the regulator pressure at 21.500 psig (148 kPag). Do
not set the regulator above 22 psig (152 kPag).
AccuPyc III Operator Manual
135-42800-01 (Rev -) — Nov 2023
P
RESSURE
Regulator Pressure
A. Gas tubing to instrument
B. Gas regulator shut-off valve
C. Low pressure gauge
D. High pressure gauge
E. Gas cylinder shut-off valve
F. Regulator connecter nut
G. Regulator control knob
H. Brass reducer fitting
3 - 63
