10.7.1 Dynamic Resistance Measurement Settings
Figure 86 shows the dynamic resistance measurement main settings. Each part is explained after
that.
To select the measuring side, when there are two OLTCs
To select the option for testing between phases or between phase and neutral, if available
To select the test current
The recovery time is the time it normally takes for the current to return to normal level and
stabilize after the tap position is changed. The next transition measurement is not started until
this time has elapsed.
90297-0.24 Instruction Manual mini-ATOS
Figure 86: Dynamic resistance measurement main settings
Preliminary
Page 99 of 125
