Figure 87 shows the dynamic settings of DRM.
Figure 87: DRM dynamic settings
To select the expected trigger level
To select whether the mini-ATOS should short circuit the other side. The mini-ATOS will
automatically engage the internal multiplexer for short circuiting
To adjust the recording time of each transition
Preliminary
90297-0.24 Instruction Manual mini-ATOS
Page 100 of 125
