The tap changer motor current measurement settings is showed in Figure 88.
Figure 88: DRM tap changer motor current measurement settings
To enable or disable the motor current measurement
To select the tap changer motor, working voltage frequency
To input the rated current of the tap changer motor. It is not necessary to enter a higher value
to account for the inrush current. The mini-ATOS automatically utilizes a higher measuring
range to accurately measure the inrush value
Preliminary
90297-0.24 Instruction Manual mini-ATOS
Page 101 of 125
