7.3 Templates

When there are some test objects with the same specifications, it is good to make a template for all
of them. Later it is possible to use the template to define each test object easier and faster by
avoiding entering the same information each time.
Figure 11 shows the template list. To create a new template, just tap the add button
the template data the same as to create a new test object (See chapter 8). You can then save it
and jump to the test plan page. Test plan is also a part of the template. It is possible to adjust the
test plan including the measurement settings.
To activate the multiselect feature for deleting multiple templates simultaneously
Filter the test object records
Sort the template items based on various fields
Search tool to find a template from the list. The search word can be the name or the winding
connection type
To create a new template
Template item
The template winding configuration
Template name
Date created
When it is marked, it will be shown on the home screen
To open the option menu
90297-0.24 Instruction Manual mini-ATOS
Figure 11: Test object templates
