12 Remote Access Instruction

With the remote connection, it is possible to access the device software from other devices such as
PC and tablets. The remote connection is possible with the USB or the network connection. When
the device is connected, the mini-ATOS can be accessed by using any web browser. For optimal
operation, we recommend using Google Chrome or Microsoft Edge browser.
The procedure to use remote access is explained as follows:
1- Please ensure that the remote access feature is enabled in the device settings (Refer to
chapter 7.4.5). If the access code was manually adjusted, make a note of it to provide it
later.
2- Connect the mini-ATOS to the PC:
•
By using the USB-B cable
•
Or by using the network cable. Make sure that the networking settings are adjusted
correctly (Please see chapter 7.4.4)
3- From the home page or the main menu, tap the logout icon
page like Figure 98
4- Activate remote access on the select profile page. If you didn't input the access key
manually in the settings, you will see then the auto-generated access key (Figure 99)
5- Open the browser in pc or tablet and then:
•
If the connection is with the USB cable, enter 192.168.11.1 in the address bar to
open the software
•
If the connection is with the Network cable, enter the hostname (you can find the
hostname in the networking settings, please see chapter 7.4.4) after the http://
(e.g., http://mini-ATOS-411-101) in the address bar to open the software
6- Enter the access key and confirm to access the software (Figure 100)
90297-0.24 Instruction Manual mini-ATOS
Figure 98: Select Profile page on the mini-ATOS display
Preliminary
to see the select profile
