14 Technical Specifications

14.1 General

Area of use
Enclosure
Supply
Rated input voltages
Absolute input voltages
Consumption power
Mains protection
Output power
Test voltage user selectable (AC)
Max. test current (AC)
Test current user selectable (DC)
Max. test voltage (DC)
Temperature measurement range
Display
Input devices
Front panel
Interfaces
Printer
Operating temperature
Storage temperature
Humidity
Pollution degree
Altitude
Degree of protection (closed door)
Degree of protection (open door)
Size
Weight (instrument)
Weight (accessories)
Shipping weight and package size
90297-0.24 Instruction Manual mini-ATOS
Portable to use indoor and outdoor including heavy
industrial electromagnetic environments
Industrial high-impact plastic case
IEC 60320, C13/C14 mains connector, CAT II
110/240 VAC @ 50/60Hz, automatic ranging
90-264 VAC @ 47-63Hz
Max. 900VA
2x 5mm x 20mm T10A Fuse
Max. 600W
10-250 VAC
1A
0.050-30A and 0.025-7.5A simultaneously
50VDC (100VDC with automatic booster)
-20°C (-4°F) to 110°C (230°F)
7" TFT Color LCD
Capacitive touch screen, support mouse and keyboard
Sealed, anodized
3 USB 2.0 full speed (2 hosts, 1 device) and Ethernet
Internal 1.9" thermal printer
-10°C (14°F) to 55° C (131°F)
-20°C ( -4°F) to 70°C (158°F)
5%-95% relative humidity, no condensation
2
Up to 2000m (without derating)
IP67, dust-tight and water immersion up to a 1-meter
depth
IP20
L: 525 mm (20.7") W: 437 mm (17.2") H: 213 mm (8.4")
16.5 kg (36.4 lbs.)
Please contact
Please contact
