8 Test Objects

8.1 Power Transformer

In the TEST OBJECT window, a new test object can be defined or an existing test object can be
modified. Figure 20 represents the test object window.
Test Object Name
Name of the test object, which is helpful for easy identification. The system always assigns an
automatic name at the beginning which consists of the test object type, date and time. This name
can be easily changed by tapping the pencil symbol or the name.
Save
Tap the Save icon to store all the entered test object data and go to the test plan.
Cancel
By tapping this icon, you can cancel the test object defining and go back to the Home Screen.
Please take care because all the entered data will not save.
90297-0.24 Instruction Manual mini-ATOS
Figure 20: The test object window
