To create a template from the test object (See chapter 7.3 for more information)
To export the test object to a USB stick
By opening each test object, the history of the inspections and test plan measurements will be
displayed as in Figure 10.
To open the main menu
To go back to the Archive
Open test object quick access
To delete the selected inspection
To generate and export the PDF report
To jump to the test plan page and perform the measurements
To add a new inspection
The list of inspections sorted by date
The selected inspection title
The selected test plan measurement sides
The test plan measurement item
The measurement type
The last measuring date and time
To open the result view in graph and table
90297-0.24 Instruction Manual mini-ATOS
Figure 10: List of measurements for each test object in Archive
Preliminary
Page 33 of 125
