7.2 Archive

In Archive, a list of already defined test objects is shown (Figure 9).
To activate the multiselect to export or delete test objects
Filter the test object records
Arrange the test object records by sorting them according to different fields
Search tool to find a test object from the list. The search word can be the name, serial number
or winding connection type
To import a test object from the connected USB stick
To create a new test object
Test object record
The test object winding configuration
Test object name
Last activity date
To open the option menu
Open the test object
Test object serial number
To delete the test object
To edit the test object
To clone the test object
90297-0.24 Instruction Manual mini-ATOS
Figure 9: The mini-ATOS test objects Archive
