4-24 Chapter 4: InView Protocol
Beg of
ADDR FUNC
Frame
: FF 01
NOTE
Beg of
ADDR
Frame
: FF
Beg of
ADDR FUNC
Frame
: FF 01
User's Manual 0300277-03 Rev. A
Response: NONE
300 ms pause
Download message file #003
Transmission is as follows:
Transmission for Downloading Message 3 (Example 1)
H.O L.O
ADDR ADDR
00 64
See InView Display Communication Protocol Functions and Descriptions
for further explanation of the InView sign protocol being used.
Response: NONE
300 ms pause
3. Clear the message queue.
This transmission is used to remove all currently running messages
downloaded to the queue.
Transmission is as follows:
Transmission for Clearing the Message Queue
H.O L.O
FUNC
ADDR ADDR
06 00
Response: NONE.
Download Two Messages with a Variable Example
This example shows downloading two messages (one with a variable). Set the
message size to 60 bytes (0×3C) for each message.
1. Set message partitions in the display(s) to 60 bytes.
Transmission is as follows:
Transmission for Setting Message Size to 60 Bytes (Example 2)
H.O L.O
ADDR ADDR
00 64
DATA
^AZ00^BA0003^["b^I^^1^\1Priority
Low^D
DATA
65 FFFF
DATA
^AZ00^BEa003C^D
Ready
EOF to rec.
response
CR LF
Ready to
LRC
rec.
EOF
Error
response
98 CR LF
Ready
EOF to rec.
response
CR LF
