Section 1.14 EMI Compliance for the 2706-P22-SC Display

Section 1.15 Download a Message Application

Chapter 1: Installing InView Message Display
Coupez l'alimentation de l'afficheur InView avant de régler tout
interrupteur. Les réglages des interrupteurs ne sont scrutés qu'à la mise
sous tension.
DIP Switch Settings
Pin Name
1 (LSB)
2
4
8
16
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with installation guidelines, may cause
harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which case the user will
be required to correct the interference at his own expense.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
North American Certifications:
UL 508
•
• UL 12.12.01 (Class I, Div 2, Groups ABCD).
CSA C22.2 No. 213
•
CSA C22.2 NO. 142-M1987
•
• FCC Part 15 Class A compliance
CE compliance to:
Low Voltage directive: 2014/35/EU
•
EN 61010-2-201
•
• EMC directive: 2014/30/EU
EN 61131-2, Programmable Controllers (Clause 8, Zone A & B)
•
EN 61000-6-4 (emission) and EN 61000-6-2 (immunity)
•
InView message applications are created using the InView messaging software
(2706-PSW1-SC). After creating the Message Application, you need to
download it into your InView display memory.
InView applications can be downloaded using:
Point-to-point serial communications (RS-232) from the communication
•
port on a personal computer.
Multi-drop RS-485 serial communications. Utilizing a 1761-NET-AIC to
•
convert RS-232 to RS-485 from a personal computer allows you to
Pin Pin Name
6
7
8 128 (MSB)
9 Diagnostics
10 Not Used
User's Manual 0300277-03 Rev. A
1-29
32
64
