3. Screw the inside and outside ends of the connector together until water-
4. Strip the electrical wires back 6.35 cm (0.25 in.).
5. Connect the wires by screwing the end of each wire into the power
6. If the sign is to be used with serial communications, remove one or both
TB1 can be used for incoming RS-485 or RS-232 serial connection. The
NOTE
full pinout diagram is shown below.
TB1 Full
Pin Pin Name
1
2
3 RS-232 TX
4 RS-232 RX
Chapter 1: Installing InView Message Display
tight.
connection.
of the hole plugs from the lowest holes on the right end of the sign case.
Otherwise, proceed to Step 7.
GND
+5 V
Pin Pin Name
5
6
7
8
User's Manual 0300277-03 Rev. A
1-17
RS-485+
RS-485-
NC
Shield
