Section 1.12 EMI Compliance for 2706-P92-SC and 2706-P94-SC Signs

Section 1.13 Mount the 2706-P22-SC Display

NOTE
Chapter 1: Installing InView Message Display
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with installation guidelines, may cause
harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which case the user will
be required to correct the interference at his own expense.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
North American Certifications:
UL 60950-1
•
CSA C22.2 No. 60950-1
•
FCC Part 15 Class A compliance
•
CE compliance to:
• Low Voltage directive: 2014/35/EU
EN 60950-1
•
EMC directive: 2014/30/EU
•
• EN55032 Class A
The following provides panel cutout dimensions and overall dimensions for the
InView P22R-SC panel mount display.
The InView P22R-SC mounts in a custom panel or enclosure. When it is properly
installed, the faceplate provides a NEMA Type 12, 13, and 4X (indoor) rating.
To mount the display:
1. Cut and drill the appropriate mounting holes in the enclosure or panel.
Refer to Panel Cutout Dimensions for 2706-P22R-SC Display earlier in
this section.
2. Remove the six mounting nuts and washers from the hardware bag
provided with the display.
3. Position the InView Display in the panel or enclosure mounting hole.
4. Install washers and nuts and alternately tighten the nuts to a torque of
0.904 Nm (8 lb-in).
InView P22R-SC mounting and panel cutout are identical to DL40 Plus,
DL40, DL20 and DL10 two-line displays.
User's Manual 0300277-03 Rev. A
1-25
