Allied Motion Spectrum Controls 2706-P22-SC User Manual page 10

1-4
NOTE
User's Manual 0300277-03 Rev. A
Chapter 1: Installing InView Message Display
4. Strip the wires back 6.35 mm (1/4-in.). Connect the incoming electrical
wires.
Be sure to place the wires so they are not caught by screws when replacing
the power supply cover, and also so that they do not interfere with fan
operation.
5. Insert the serial wires through the right conduit hole on either the top or
the bottom of the sign.
