Section 1.10 Mount the 2706-P92-SC and 2706-P94-SC Displays

NOTE
Chapter 1: Installing InView Message Display
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at
his own expense.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
North American Certifications:
UL 60950-1
•
CSA C22.2 No. 60950-1
•
FCC Part 15 Class A compliance
•
CE compliance to:
Low Voltage directive: 2014/35/EU
•
• EN 60950-1
EMC directive: 2014/30/EU
•
EN55032 Class A
•
To mount the sign:
1. Attach the two sign brackets to a wall, ceiling, or other surface.
2. Be sure to place the brackets so the bracket flanges face appropriately as
shown below. Mount the brackets the following distance apart (measured
from the center of the mounting holes in each bracket):
Do not install the sign directly to drywall or plaster-board. The sign must
be fastened to a wall capable of supporting at least four times the weight
of the sign.
3. Mount the sign on the sign brackets using the two large hex bolts
supplied.
4. Insert the bolts into the far single holes first, until the desired viewing
angle is determined.
User's Manual 0300277-03 Rev. A
1-19
