time. Second, clear the queue.
The following is an example of setting the time to 1034 and the format for the
time to be AM/PM.
Transmission for Setting Time with AM/PM Format
Beg of
ADDR FUNC
Frame
: FF 01
NOTE
The following transmission is used to remove the time that was just loaded into
the message queue.
Transmission is as follows:
Transmission for Clearing the Message Queue
Beg of
ADDR FUNC
Frame
: FF 06
Response: NONE
Set Time in Broadcast Mode with 24-Hour Format
This command is used to set the time and the format for the time in all displays.
This is primarily done using the automation software to synchronize the time in
the displays with the computer. This requires two separate transmissions. First,
set the time and format for the time. Second, clear the queue. The following is an
example of setting the time to 1034 and the format for the time to be 24-hour
(military) format:
Transmission for Setting Time with AM/PM Format
Beg of
ADDR FUNC
Frame
: FF 01
1. Set the time and time format.
Transmission is as follows:
H.O L.O
ADDR ADDR
00 64
See InView Display Communication Protocol Functions and Descriptions
on for further explanation of the InView sign protocol being used.
Response: NONE
300 ms pause.
2. Clear the message queue.
H.O L.O
ADDR ADDR
00 65
1. Set the time and time format.
Transmission is as follows:
H.O L.O
ADDR ADDR
00 64
Chapter 4: InView Protocol
DATA
^AZ00^BE
1034^C^BE'S^C^D
DATA
FFFF
DATA
^AZ00^BE 1034^C^BE'S^C^D
User's Manual 0300277-03 Rev. A
Ready to
EOF rec.
response
CR LF
Ready to
LRC
rec.
EOF
Error
response
98 CR LF
Ready to
EOF rec.
response
CR LF
