1-8
NOTE
User's Manual 0300277-03 Rev. A
Chapter 1: Installing InView Message Display
1. Before you mount a display, disconnect power.
Remove only one end cap at a time.
Wall Mount
To mount a display on a wall:
1. Remove the 4 screws and end cap from one end of the sign.
2. Slide one of the wall mounting brackets onto the back of the sign until it
is approximately 13 mm (0.5 in.) away from the end of the sign.
3. Use two 10-32 × 1/4 Phillips screws (supplied) to secure the wall
mounting bracket to the back of the sign.
