4-18 Chapter 4: InView Protocol
NOTE
Beg of
ADDR FUNC
Frame
: FF 06
Beg of
ADDR FUNC
Frame
: FF 01
NOTE
User's Manual 0300277-03 Rev. A
See InView Display Communication Protocol Functions and Descriptions
on for further explanation of the InView sign protocol being used.
Response: NONE
300 ms pause.
2. Clear the message queue.
The following transmission is used to remove the time that was just loaded into
the message queue.
Transmission is as follows:
Transmission for Clearing the Message Queue
H.O L.O
ADDR ADDR
00 65
Response: NONE
Set Time in Broadcast Mode with 24-Hour Format
This command is used to set the time and the format for the time in all displays.
This is primarily done using the automation software to synchronize the time in
the displays with the computer. This requires two separate transmissions. First,
set the time and format for the time. Second, clear the queue. The following is an
example of setting the time to 1035 and the format for the time to be 24-hour
(military) format.
1. Set the time and time format.
Transmission is as follows:
Transmission for Setting Time with 24 Hour Format
H.O L.O
ADDR ADDR
00 64
See InView Display Communication Protocol Functions and Descriptions
on for further explanation of the InView sign protocol being used.
Response: NONE
300 ms pause.
2. Clear the message queue.
DATA
FFFF
DATA
^AZ00^BE 1035^C^BE'M^C^D
Ready to
LRC
EOF rec.
Error
response
98 CR LF
Ready to
EOF rec.
response
CR LF
