2-4 Chapter 2: InView System Connectivity
NOTE
Section 2.6 DIP Switch Settings
Pin
1
2
3
4
3
User's Manual 0300277-02 Rev. C
After one complete LED scan is done, a RAM check is performed, and the
display's memory is cleared. To ensure that the display's memory is not
cleared, turn off power to the display after the LED block test is
performed. Make sure that the download or message file has been saved
before the diagnostic test is allowed to run completely through.
2706-P22-SC Display Dip Switch Settings
Pin Name
1 (LSB)
2
4
8
16
Dip Switch Information for the 2706-P9x-SC
There are two dip switches located on the controller board, Switch 1 and Switch
2.
2706-P9x-SC Dip Switch
Switch 1
Switch 1 is used to configure the display's RS-485 echo enable, communication
rate settings, and display size.
Pin Pin Name
6
7
8 128 (MSB)
9 Diagnostics
10 Not Used
32
64
