A-4 Appendix A: Installing InView Marquee 2706-P9xC2-SC Message Displays
NOTE

Wiring the 2706-P92C2-SC and 2706-P94-SC Displays

WARNING
WARNING
User's Manual 0300277-03 Rev. A
Back-to-Back Mount
To connect the sign:
1. Attach the brackets to the sign in the ceiling mount position with the hex
bolts supplied:
2. Match the signs together back-to-back and connect them together using a
total of six 5/16" bolts and nuts (not supplied).
3. Attach chains (not supplied) to the top mounting holes of the bracket to
hang the signs from the ceiling.
Use chains capable of supporting 4 times the total weight of the signs.
Hazardous voltage.
Contact with high voltage may cause death or serious injury.
Always disconnect power to the InView display prior to servicing.
Maintain separation of circuits. Route the incoming power directly to the
power connections terminal block.
Do not run the power wiring over the logic board.
Tension dangereuse.
Toucher un câble a haute tension peut provoquer la mort ou des
blessures graves.
Sortir la prise d'alimentation de l'afficheur avant de le réparer.
Maintenir la séparation des câbles.
Brancher le câble d'alimentation directement au bornier d'alimentation
électrique.
Ne pas faire cheminer le câble d'alimentation le long de la carte
