B-12 Appendix B: Installing InView Marquee 2706-P4xC2-SC Message Displays
WARNING
WARNING
NOTE
User's Manual 0300277-03 Rev. A
Hazard of damage to electronic equipment.
Failure to ensure that jumper J2 is in the correct position for the
voltage supplied to the InView Comms module can result in
damage to the module circuitry.
Before applying power to the InView Comms Module, check that the
jumper is in the correct position for your application.
Danger de dommage pour l'équipement
S'assurez que le cavalier J2 est dans la position correcte pour la
tension fournie au module de communication InView sinon cela
pourrait entrainer des dommages a l'ensemble des circuits du module.
InView en tension, vérifiez que le cavalier est dans la position de voltage
adequat pour votre application.
The 2706-PENETM2C2-SC communication modules are provided with
cable PN 6010104-nn, (3 meters long). The cable combines power and
serial communications. Power for the communications module comes
from display terminals #6 and #7. Serial communications are via RS-232
from the module to the display using terminals #8 and #9.
5. Tighten the cable grip cap until the cable is securely fastened.
6. Replace the rear panel power cover with the 4 screws and tighten the
screws to 2.7 N-m (24 in-lb).
7. Connect the power supply to a power source.
8. If you press the reset button in the module, the module restarts,
initializes, and displays the Communications Module's MAC address, its
Ethernet IP address, and its Gateway IP addresses as part of the
associated InView display.
9. Write down the values. Example: 192.168.1.100
10. Connect your PC to the other end of the Ethernet network cable installed
in ETH1 on the Comms module and start an Internet browser.
11. In the Address field, type in the IP address you obtained from the display
to which the Comms Module is connected.
12. Example entry only. Your address may be different: 192.168.1.100
13. The InView User Interface software starts up and provides you with a
login screen. Enter the default password:
spectrum
The main InView User Interface View window appears.
14. Use the online help to finish setting up your InView and display.
15. Follow directions. If needed, click Help button for specific instructions:
électronique.
