4-38 Chapter 4: InView Protocol
Command Code, continued
Set Hour and Minutes HhMm
HhMm 1034 (Example)
HhMm 0945 (Example)
H = ASCII digit for hours (10's
digit)
h = ASCII digit for hours (1's digit)
M = ASCII digit for Minutes (10's
digit)
m = ASCII digit for Minutes (1's
digit)
<STX>
Description ASCII
Start of
^B
Text
Description
End of Transmission
<SOH>
Description ASCII
Start of
^A
Header
<STX>
Description ASCII
Start of
^B
Text
User's Manual 0300277-03 Rev. A
Set Time
ASCII
1034
0945
Command Code
Hex Description
Set Time
Format
42
AM/PM
Set Time
Format 24 Hr
(Military)
Set Date
This command is used to set the date.
Format for displaying the date is shown under Insert Object later in this section.
Special Function Command to Set Time and Date
