User's Manual 0300277-03 Rev. A
Chapter 1: Installing InView Message Display
Stack Mount
Up to 4 signs can be hung together vertically ('stacked'). Mounting system
for stack mounting must support a minimum of four times the total weight
of all signs being stacked.
Possible crush Hazard.
Stacking too many signs may cause signs to fall causing serious injury or
death.
Do not stack more than 4 signs.
Danger de chute possible.
Ils risquent de tomber et d'entraîner des blessures graves voire la mort.
N'empilez pas plus de 4 afficheurs sinon.
To stack the signs:
1. Remove the top screw from each end cap of the bottom sign.
2. Use the screw removed in Step 1 to fasten a stacking bracket to each
end cap, countersunk side out, and torque to 2.7 Nm (24 lb-in).
3. Remove the top and bottom screws from each end of the remaining
signs.
4. Remove the top and bottom screws from each end of the remaining
signs.
