4 Original exit sensor
5 Original exit (top)
6 Original exit (rear)
[B] Roll paper paths
7 Roll end sensor (Roll Unit 2)
8 Paper entrance sensor (Right, Roll Unit 2)
9 Paper entrance sensor (Center, Roll Unit 2)
10 Exit sensor (Roll Unit 2)
11 Roll end sensor (Roll Unit 1)
12 Paper entrance sensor (Right, Roll Unit 1)
13 Paper entrance sensor (Center, Roll Unit 1)
14 Exit sensor (Roll Unit 1)
15 Pre-registration sensor
16 DRESS sensor
17 Exit sensor
[C] Bypass paper path
18 Bypass sensor
19 Registration standby position
20 Paper standby position (Roll 1)
21 Paper standby position (Roll 2)
