Cut Length (mm)
to 3000
to 3600
to 15,000

Step 11: Synchro Cut (Trailing Edge Registration)

The following SPs are used in this step:
• SP4-961-001 (Document Length Adjustment – Input Tolerance 210 mm)
• SP4-961-002 (Document Length Adjustment – Input Tolerance 1000 mm)
• SP4-961-003 (Document Length Adjustment – Check Document Length)
1. Prepare two originals
• 1 original 210 mm long (A4 LEF)
• 1 original 1000 mm long (measure and cut)
2. Go into the SP mode and do SP4-961-001.
3. Touch [COPY Window] and copy the 210 mm sheet that you prepared in Step 1.
4. Touch [SP Mode] to go back to the SP mode.
5. Do SP4-961-003 to check the original scan length.
6. If the display is different, adjust with SP4-961-001.
7. Do SP4-961-002.
8. Touch [COPY Window] and scan the 1000 mm sheet that you prepared in Step 1.
9. Touch [SP Mode] to go back to the SP mode.
10. Do SP4-961-003 to check the scan length.
11. If the display is different, adjust with SP4-961-002.
Cut Length (mm)
Less than 297
Cut Tolerance (mm)
±11
±14
±150
Cut Tolerance (mm)
to 594
to 841
to 1219
to 2000
±4.50
±5.00
±6.00
±8.50
±18.0
Special Adjustments
