Fuses

Scanner Unit

Operation Panel

Refer to Smart Operation Panel Manual.

SIB (Scanner I/F Board)

The SIB is placed at the left back of the scanner unit, controls the CIS, scanner motor, and sensors on the
scanner motor, and relays the signals.
The CIS reads image data, which are then converted from analog to digital and sent to the BiCU.
LED Status
LED Color
LED1 Green
Fuse
Output
Name
terminal
CN436
FU1
CN438
LED Status
Power ON: Lit
Power OFF / Sleep mode: not lit
Capacity Voltage
1.1 A
5 V
8 V DC
Type
Sensors for scanner
11090007
unit
Fuses
Part No.
