CONTROL PANEL

8 CONTROL PANEL
8.1

General settings

8.1.1

Selecting kilovolt and milliampere values

34 ProMax X-ray unit with Dimax3
To make a selection on the control panel, simply touch the
screen with your finger on a text field or on an icon. For
example, to select the program type touch the Prog. field
with your finger. You will hear a signal tone when a field or
an icon is activated.
To cancel a selection, touch the Cancel field.
Only the text fields and icons on the screen are touch-
sensitive, and touching areas outside them will not
activate an action.
Screen saver mode will be switched on when the control
panel has been untouched for 30 minutes. When in
screen saver mode, the Ready/Pret light on the right-hand
side of the screen and the indicator light on the exposure
switch will come on. Touching the screen will activate the
control panel again.
NOTE The position of the control panel can be changed
by moving the control panel to the right or left.
NOTE The contents of the control panel displays
depend on the unit configuration. The displays
shown here are from a SCARA3 unit featuring all
currently available imaging programs. SCARA3
units have three joints.
NOTE Refer to the Cephalostat user's manual for
information on how to select the cephalometric
exposure program.
Touch the kV/mA field on the main display.
