PROGRAMS
3x PA Sinus & Nasal
Automatic, 3 posteroanterior images from sinus area/midsagittal
plane (nasal cavity).
NOTE In this program, the selected target position is
image no. 2.
Longitudinal tomographic exposure programs
4x LNG Manual
Manual, 1-4 longitudinal images.
Distance (middle to middle) between the target points is
adjustable.
3x LNG Autoposition
Automatic, 3 longitudinal images. The exposure position is
automatically moved between exposures. The movement is
adjustable, and it can be either 1, 3, 6, 9 or 12mm. Distance
(middle to middle) between the target points is adjustable.
NOTE The selected target position is image no. 2.
22
ProMax X-ray unit with Dimax3
3.
2.
3.
2.
Left
Right
1.
1.
SINUS
3
2
1
Left
3 2 1
NASAL
3
2
1
3xLNG_Manual.eps
4xLNG_Auto_pos.eps
