Bite piece
User's Manual
NOTE
NOTE
Patient position with
the chin support
Temple
support
button
Ask the patient to step forward, grasp the patient handles,
stretch up and bite the bite piece. The incisal edges of the
maxillary and mandibular teeth must be in the groove in
the bite piece.
If you are using the chin support, position the
patient so that the chin, just below the lower lip,
touches the top bar.
If you are using chin cup or support use for
example roll gauze to ensure that the patient's
teeth are together.
Close the temple supports by pressing the temple support
button.
ProMax X-ray unit with Dimax3 67
PANORAMIC EXPOSURE
