CONTROL PANEL
Distance
Size
Target
50 ProMax X-ray unit with Dimax3
Select the distance between the exposures by touching
the Distance field. The distance can be 1, 3, 6, 9 or
12mm, and the list is cyclical.
Select a standard (either lower or upper collimation) or full
size (full collimation) exposure by touching the Size field.
If you select Standard only the selected jaw will be
exposed, and selecting Full will produce a full size
exposure of both jaws.
Select the tooth number (0-8) or temporomandibular joint
(9) by touching the Target field. The number 0 indicates
the space between the central incisors. The list is cyclical.
NOTE The target selection can also be made by simply
touching the jaw icon on the corresponding
location.
NOTE The selected target position is image no. 1. In
automatic programs the selected target position
is image no. 2. Refer to the program lists on
previous pages.
When you have set the target position, confirm the
selections by touching the OK field. The main display
appears.
