Wide jaw
Between incisors
Upper:
Right-hand side coordinates -
X-coordinate is positive
on the left-hand side.
Condyle
Nasal area
Sinus
User's Manual
Tomography
wide jaw
upper
Coordinates of the target sites
upper
target
x y
(tooth)
0 0 -1
1 -3 -1
2 -9 0
3 -13 2
4 -17 6
5 -21 12
6 -24 20
7 -27 31
8 -30 41
9 -55 81
10 0 21
11 -25 21
y
-90º
+90º
lower
angle x y
90 0 -7
87 4 -7
77 10 -5
60 15 -2
39 21 2
28 26 8
21 31 16
13 36 26
13 41 36
17 55 81
0
0
ProMax X-ray unit with Dimax3 27
PROGRAMS
1 cm
x
lower
0º
angle
90
83
Lower:
71
Left-hand side coordinates -
X-coordinate is negative
59
on the right-hand side.
46
34
30
29
27
17
