DIGITAL PROMAX X-RAY SYSTEM - MAIN PARTS
Patient supports
Bite piece
Adapter
Emergency stop button
8 ProMax X-ray unit with Dimax3
Chin rest
When driving the X-ray unit from one position to another
care should be taken. In case of an emergency press the
stop button on top of the stationary column to stop the
possible on-going exposure and up/down movement of
the X-ray unit.
HE 141 appears in the display.
Pull up the emergency stop button. The X-ray unit will be
automatically rebooted. The X-ray unit is ready for use
again.
Press and pull up
Chin cup
Chin support
