Raption 150 Compact Service Manual
A
CCS holder adjustment
The CCS holder retainers comes with a standard factory setting, which ensures the
use of the connector by most users, and guarantees the position of the connector
in the holder during periods of rest, preventing it of falling.
Locate it in the Charge Point left door (also in right door if Charge Point is CCS-
CCS model). Pull CCS connector out and put it in. Decide by yourself, according to
strength used, if connector pressure needs to be loosened or tightened.
The adjustable retainer system is located inside the Charge Point.
A technical procedure manual is available to download in Circontrol Expert Area
explaining step by step how to adjust the pressure in each CCS holder.
81
